JLG 26MRT Parts Manual User Manual
Page 44
2-24
3120893
SECTION 2 GROUND COMPONENTS
S
E
C
T
I
O
N
2
G
R
O
U
N
D
C
O
M
P
O
N
E
N
T
S
35
0700812
Bolt, Metric 8mm x 25mm
27
36
4751500
Flatwasher 5/16”
11
37
0100011
Loctite #242 (Not Shown)
A/R
38
0700805
Bolt, Metric 6mm x 10mm
6
39
0641508
Bolt 5/16”-18NC x 1”
3
40
2720058
Hose, Fuel Line (5/16”)
6ft/1.8m
41
1320022
Clamp, Hose
6
42
0641812
Bolt 1/2”-13NC x 1 1/2”
2
43
4751800
Flatwasher 1/2”
2
44
Bolt Options:
2
0701012
Bolt, Metric 10mm x 25mm (Prior to S/N 66750)
0641608
Bolt, 3/8”-16NC x 1” (S/N 66750 to Present)
45
1320016
Clamp, Hose
6
46
1701505
Decal - Diesel Fuel (Not Shown - Located on Hood)
1
47
2750532
Hose (3/8”)
1ft/30.5cm
48
0080221
Adapter, Pump Mounting
1
49
1320026
Clamp, U-Bolt
1
50
0641406
Bolt 1/4”-20NC x 3/4”
4
51
4751400
Flatwasher 1/4”
4
52
3311405
Locknut 1/4”-20NC
4
53
Plug, Pipe Options:
1
2200213
Prior to S/N 58575
2200233
S/N 58575 to Present
54
Fitting, 90
°
Options:
1
2200462
Prior to S/N 44924
2220648
S/N 44924 to Present
55
2180666
Fitting, Barbed
1
56
1660222
Coupling, Throttle
1
57
3321402
Nut, Jam 1/4”-28NF
1
58
3321602
Nut, Jam 3/8”-24NF
1
59
1660220
Swivel, Throttle
1
60
4740442
Washer, Belleville
1
61
3900217
Bolt, Socket Head Shoulder
1
62
0962031
Bushing, Flanged
1
63
Not Used
64
2220250
Fitting, Reducer
2
65
2180348
Fitting, Barbed
1
66
2720271
Hose, Fuel (3/16”)
6
67
4569675
Tube, Air Intake
1
68
4811700
Flatwasher 6mm
6
69
1060221
Strap, Ground (Starter to Engine Tray)
1
70
2720422
Hose, Radiator (Top)
1
71
Clamp, Hose Options:
4
1320014
Prior to S/N 44432
1320033
S/N 44432 to Present
72
0701015
Bolt, Metric 10mm x 35mm
8
73
4740185
Washer, Hardened
2
74
Not Used
FIGURE 2-6. YANMAR DIESEL ENGINE INSTALLATION (CONTINUED)
FIG & ITEM #
PART NUMBER
DESCRIPTION
QTY.
REV.
