3120893 2-9
SECTION 2 GROUND COMPONENTS
S
E
C
T
I
O
N
2
G
R
O
U
N
D
C
O
M
P
O
N
E
N
T
S
.
FIGURE 2-3. VANGUARD GAS ENGINE INSTALLATION (PRIOR TO S/N 48113)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
0255959 VANGUARD ENGINE ASSEMBLY & INSTALLATION (PRIOR
TO S/N 48113) Ref. 14
1 3539676 Shroud, Fan 1
2 1340033 Cap, Air Intake 1
3 3539465 Plate, Mounting (Radiator) 1
4 2000140 Engine - Vanguard DM700G (See Items 101-130 for Break-
down) 1
5 3600256 Piston Pump Assembly (See Figure 2-7 for Breakdown) 1
6 See Note Gear Pump Assembly (was p/n 3600257) 1
Note: P/N 3600257 no longer available. Use p/n 3600466.
New pump includes required fitting. Ref.
7018924 Seal Kit (Includes Shaft Seal) 1
7018923 Seal, Shaft 1
7 3539459 Plate, Mounting (Rear Right Side) 1
8 3539460 Plate, Mounting (Rear Left Side) 1
9 3539461 Plate, Mounting (Front) 1
10 3200381 Mount, Motor 3
11 1340057 Air Cleaner Assembly 1
11A 7015004 Element, Filter 1
11B 7015005 Cover Assembly 1
11C 7015006 Valve, Vacuator 1
11D 7015007 Latch 2
12 0340045 Band, Mounting 1
13 3539484 Plate, Mounting (Air Cleaner) 1
14 to 15 Not Used
16 3620035 Radiator 1
7016606 Cap, Radiator 1
7019618 Draincock 1
17 2901414 Fan Kit 1
18 1700430 Decal - Gas (Not Shown - Located on Hood) 1
19 4567104 Pipe, Exhaust 1
20 0902270 Bracket 1
21 2540032 Grommet 2
22 0641506 Bolt 5/16”-18NC x 3/4” 2
23 3311505 Locknut 5/16”-18NC 5
24 0641608 Bolt 3/8”-16NC x 1” 7
25 3311605 Locknut 3/8”-16NC 6
26 0641818 Bolt 1/2”-13NC x 2 1/4” 3
27 3311805 Locknut 1/2”-13NC 3
28 Not Used
29 Use 2910000 Actuator Assembly (Was p/n 0060037) (See Section 7 for
Breakdown) 1
30 3841315 Rod, Throttle 1
31 3220109 Muffler 1
32
33 4740274 Washer, Snubbing 3
34 4751600 Flatwasher 3/8” 6
35 0700810 Bolt Metric 8mm x 20mm 12
