3120893 2-31
SECTION 2 GROUND COMPONENTS
S
E
C
T
I
O
N
2
G
R
O
U
N
D
C
O
M
P
O
N
E
N
T
S
.
FIGURE 2-9. GROUND CONTROLS INSTALLATION
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
GROUND CONTROL BOX ASSEMBLY OPTIONS: Ref.
0256308 Vanguard (Prior to S/N 35428) Ref. 6
0256740 Vanguard (S/N 35428 to Present) Ref. 6
0256309 Yanmar (Prior to S/N 35428) Ref. 6
0256741 Yanmar (S/N 35428 to Present) Ref. 4
1 Box Options: 1
4844562 Prior to S/N 70893
0861338 S/N 70893 to Present
2 3252491 Lid 1
3 4420037 Strip, Rubber 3ft/1m
4 3740049 Relay A/R
5 4761400 Lockwasher 1/4” A/R
6 3311401 Locknut 1/4”-20NC A/R
7 3640865 Rail, Terminal 1
8 4460298 Block, Terminal 35
9 4460301 Marker, Terminal (1-50) 1
10 4460299 Stop, Terminal 2
11 4460300 Barrier, Terminal 1
12 4460309 Bar, Buss - 3 Position 1
13 4460305 Screw, Buss Bar 3
14 4460306 Washer, Buss Bar 3
15 4460307 Sleeve, Buss Bar 3
16 4360216 Breaker, Circuit - 30 Amp 1
17 4770600 Starwasher #6 4
18 3310601 Nut #6-32NC 4
19 4360232 Breaker, Circuit - 15 Amp 1
20 4761000 Lockwasher #10 A/R
21 3311001 Nut #10-24NC 10
22 4460051 Connector, Strain Relief - 3/4” A/R
23 4460071 Connector, Strain Relief - 1/2” 2
24 3300048 Locknut, Conduit 4
25 0960238 Bushing 4
26 2920028 Lamp - Yellow 5
27 2920029 Bulb, Light 5
28 Not Used
29 4360387 Switch, Push Button 1
30 0100035 Loctite (Not Shown) A/R
31 3790012 O-Ring 1
32 4360431 Switch, Key 1
32A 7016339 Key, Replacement 1
33 4360395 Switch, Mushroom (Prior to S/N 58371) 1
7016315 Cap 1
4360289 Switch, Mushroom (S/N 58371 to Present) 1
7012611 Cap 1
7012612 Boot 1
34 4360314 Switch, Toggle 1
35 2600161 Hinge 1
