2-32 3120893
SECTION 2 GROUND COMPONENTS
S
E
C
T
I
O
N
2
G
R
O
U
N
D
C
O
M
P
O
N
E
N
T
S
36 3911008 Screw #10-24NC x 1/2” 7
37 3990010 Diode, 600V (Not Shown) 2
38 3300177 Nut, Tinnerman 2
39 4740120 Washer, Nylon 5
40 0750806 Screw #8-32NC x 3/4” 2
41 4460303 Terminal, Ground Block 2
42 1701683 Decal - Relay Function 1
43 3520026 Plug 1
44 4460234 Mount, Cable Tie (Not Shown) 11
45 2420033 Wire, Tie (Not Shown) 11
46 Harness - Ground Control Box Options (See Section 7 for
Breakdown) (Not Shown): 1
4921836 Prior to S/N 35428
4921897 S/N 35428 to Present
47 Harness - Engine Options: (See Section 7 for Breakdown) 1
4921837 Vanguard (Prior to S/N 35428)
4921898 Vanguard (S/N 35428 to S/N 48113)
4922182 Vanguard (S/N 48113 to Present)
4921839 Yanmar (Prior to S/N 35428)
4921900 Yanmar (S/N 35428 to Present)
48 Harness - Valve Options: (See Section 7 for Breakdown) 1
4921838 Prior to S/N 35428
4921899 S/N 35428 to Present
49 Not Used
50 2420009 Hourmeter 1
51 Not Used
52 Harness - Light Bank Diode Options: (Not Shown) (See
Section 7 for Breakdown) 1
4921907 Prior to S/N 35428
4921910 S/N 35428 to Present
53 Harness - Steer Dump Options: (Not Shown) (See Section
7 for Breakdown) 1
4921906 Prior to S/N 35428
4921909 S/N 35428 to Present
54 Harness - High Engine Lift Options: (Not Shown) (See Sec-
tion 7 for Breakdown) (S/N 32436 to Present) 1
4621905 Vanguard (Prior to S/N 35428)
4621908 Vanguard (S/N 35428 to Present)
Not Required Yanmar
55 Harness - Mid Engine Lockout Options: (Not Shown) (See
Section 7 for Breakdown) (S/N 32436 to Present) 1
4921960 Prior to S/N 35428
4921961 S/N 35428 to Present
56 3321001 Nut #10-32NF 4
57 4070987 Shim, Nylon (S/N 65027 to Present) 5
58 3910804 Screw #8-32NC x 1/4” (S/N 65027 to Present) 6
59 0641406 Bolt 1/4”-20NC x 3/4” (S/N 70893 to Present) A/R
60 0721004 Bolt #10-24NC x 1/2” (S/N 70893 to Present) 3
61 0722603 Bolt #6-32NC x 3/8” (S/N 70893 to Present) 4
FIGURE 2-9. GROUND CONTROLS INSTALLATION (CONTINUED)
FIG & ITEM # PART NUMBER DESCRIPTION QTY. REV.
