SECTION 1 - SPECIFICATIONS
3120636 – JLG Lift – 1-3
Machine Weight
100HX - 36,400 lbs. (16,511 kg)
110HX - 40,410 lbs. (18,330 kg)
100HX+10 - 39,685 lbs. (18,001 kg)
Machine Stowed Height
9 ft. 10 in. (3.0 m)
Machine Stowed Length
100HX - 36 ft. in. (11.0 m)
110HX - 38 ft. 7 in. (11.8 m)
100HX+10 - 44 ft. 2 in. (13.5 m)
Machine Width
With axles retracted - 8 ft. 6 in. (2.6 m)
With axles extended - 10 ft. 10 in. (3.3 m)
Wheelbase
11 ft. (3.4 m)
Maximum Tire Loads





1.4 TORQUE REQUIREMENTS
NOTE: See Procedure Section for tightening sequence of
turntable bearing bolts.
NOTE: When maintenance becomes necessary or a fas-
tener has loosened, refer to the Torque Chart to
determine proper torque value.
1.5 LUBRICATION
Ford LSG423 & LRG423 & LRG425 Engines
Single Viscosity Oils (SF, SF-SE, SF-CC, SF-CD)
Multi-Viscosity Oils (CD-SE, CD-SF)
* This viscosity can be used at colder temperatures only
with engine oil preheating.
Table 1-1.Maximum Tire Loads
Max. Load Max Bearing Pressure
Description Lbs. Kg PSI kg/cm 2
100HX 19900 9027 145 10
100HX+10 23740 10769 172 11.8
110HX 21540 9771 156 10.7
When Outside Temp is Consistently
Use SAE Viscosity
Number
-10° to +60° F (-24° to +16° C) *10W
+10° to +90° F (-12° C to +32° C) 20W-20
Above +32° F (0° C) 30
Above +50° F (+10° C) 40
When Outside Temp is Consistently
Use SAE Viscosity
Number
Below +10° F(-12° C) *5W-20
(Synthetic)
Below +60° F(+16° C) 5W-30
-10° to +90° F(-24° to +32° C) 10W-30
Above -10° F(-24° C) 10W-40 or 10W-50
Above +20° F( -7° C) 20W-40 or 20W-50
Table 1-2.Torque Requirements
Description
Torque Value
Interval
Hours
Ft. Lbs. Nm
Bearing to Chassis 220 298 50/600*
Bearing to Turntable 220 298 50/600*
Wheel Lugs 300 407 100
Turntable Springs 75 102 200
Boom Chains 59 80 500
Platform Rotator Bolt 140 190 500
* Check swing bearing bolts for security after first 50 hours of
operation and every 600 hours thereafter.
