SECTION 6 - JLG CONTROL SYSTEM
3121234
– JLG Lift –
6-35
6
Tilt:
1=5Deg
2=4Deg
3=3Deg
Displays/adjusts tilt
sensor function
1
2
3
5 degree – reduces the maxi-
mum speed of all boom func-
tions to creep when tilted and
above elevation. Reduces
drive speed to creep when
tilted ANSI (US); ANSI
(EXPORT); CSA; JAPAN-All
Models
4 degree - reduces the maxi-
mum speed of all boom func-
tions to creep when tilted and
above elevation. Reduces
drive speed to creep when
tilted. CE; AUSTRALIA -
Model 400S Only
3 degree – reduces the maxi-
mum speed of all boom func-
tions to creep when titled and
above elevation. Reduces
drive speed to creep when
tilted. CE; AUSTRALIA - Mod-
els 450, 600, 601, and 680.
1
1
7
Tower Lift:
0=NO
1=YES
Displays/adjusts
tower lift presence
0
1
No Tower Lift installed
Yes
1
0
8
Tower Tele:
0=NO
1=YES
Displays/adjusts
tower telescope
presence
0
1
No Tower Telescope installed
Yes
1
0
9
Jib:
0=NO
1=YES
2=SIDESWING
Displays/adjusts jib
presence
0
1
2
No Jib installed
Jib installed which has up
and down movements only
Jib installed which has up
and down movements and
side to side movements
1
0
10
4ws
0=NO
1=YES
Displays/adjusts 4
wheel steer pres-
ence
0
1
No 4 wheel steer installed
Yes
1
0
11
soft touch
0=NO
1=YES
Displays presence
of soft touch sys-
tem
0
1
No Soft Touch System
installed
Yes
1
0
12
generator
0=NO
1=YES
Displays presence
of generator
0
1
No Generator installed
Yes
1
0
Table 6-4. Machine Configuration Parameters
