SECTION 1 - SPECIFICATIONS
3121234
– JLG Lift –
1-1
SECTION 1. SPECIFICATIONS
1.1 OPERATING SPECIFICATIONS
1.2 SPECIFICATIONS AND PERFORMANCE
DATA
Table 1-1. Operating Specifications
Maximum Work Load (Capacity)
Unrestricted:
Restricted
500 lb (230 kg)
Refer to Capacity Decals on
machine for restricted platform
capacities
Maximum Travel Grade (Gradeability)*
2WD
4WD
30%
45%
Maximum Travel Grade (Side Slope)*
5°
Maximum Vertical Platform Height:
68 ft. (20.7 m)
Maximum Horizontal Platform Reach
59 ft. (17.9 m)
Turning Radius (outside)
22 ft. 6 in. (6.8 m)
Turning Radius (inside)
12 ft. (3.6 m)
Maximum Drive Speed:
3.5 mph (1.5 m/s)
Max. Hydraulic System Pressure
4500 psi (310 Bar)
Maximum Wind Speed
28 mph (12.5 m/s)
Maximum Manual Force
400 N
Electrical System Voltage
12 Volts
Gross Machine Weight
(Platform Empty)
34,700 lbs. (15,740 kg)
* With boom in stowed position
Table 1-2. Specifications and Performance Data
Swing
360°
Tail Swing
4’8" (1.42 m)
Platforms
36" x 72" (0.91m x 1.83m)
36" x 96" (0.91m x 2.44m)
Overall Width
8’ 2" (2.5 m)
Stowed Height
9’ 10.6" (3.01 m)
Stowed Length
37’ 3.25" (11.4 m)
Wheel base
10’ (3.04 m)
Ground Clearance
15.625" (0.4 m)
Drive Speed
Stowed 2WD
Stowed 4WD
Elevated
3.0 mph (5.5 kph)
3.5 mph (5.6 kph)
0.75 mph (1.2 kph)
Ground Bearing Pressure
15-625
15-625FF
41/18LLx22.5
72 psi (5.0 kgm/cm
2
)
79 psi (5.5 kgm/cm
2
)
68 psi (4.8 kgm/cm
2
)
Max. Tire Load
15-625
15-625FF
41/18LLx22.5
16,900 lbs. (7665 kg)
17,200 lbs. (7802 kg)
17,300 lbs. (7850 kg)
