SECTION 6 - JLG CONTROL SYSTEM
6-18 – JLG Lift – 3121234
Machine Personality Settings
NOTE: Personality settings can be adjusted within the
adjustment range in order to achieve optimum
machine performance.
Table 6-1. Personality Ranges/Defaults
FUNCTION PERSONALITY RANGE DEFAULTS
DRIVE ACCELeration 0.1s to 5.0s 2.0
DECELeration 0.1s to 3.0s 2.0
MINimum speed (Fwd. & Rev.) 0 to 35% 4
MAXimum speed (Fwd. & Rev.) 0 to 100% 30
ELEVATED MAXimum speed 0 to 50% 20
CREEP MAXimum speed 0 to 50% 20
Engine RPM 800 to 2900 1800
LIFT ACCELeration 0.1 to 5.0 2.5
DECELeration 0.1 to 3.0 1.0
MlNimum UP speed 0 to 60% 10
MAXimum UP speed 0 to 100 75
CREEP Maximum UP speed 0 to 65 30
MINimum DOWN speed 0 to 60 10
MAXimum DOWN speed 0 to 100 76
CREEP maximum DOWN speed 0 to 75 30
Engine RPM 800 to 2900 1800
SWING ACCELeration 0.1 to 5.0s 2.7
DECELeration 0.1 to 3.0s 2.0
MINimum LEFT speed 0 to 50% 22
MAXimum LEFT speed 0 to 100% 76
CREEP maximum LEFT speed 0 to 65% 55
MINimum RIGHT speed 0 to 50% 22
MAXimum RIGHT speed 0 to 100% 78
CREEP maximum RIGHT speed 0 to 65% 55
Engine RPM 800 to 2900 1400
