Section 3 - Controls and Indicators
3-3 31200744
1. Transmission Control Lever: See page 3-10.
2. Instrument Panel: See page 3-6.
3. Steering Wheel: Turning the steering wheel to the left or right steers the
machine in the corresponding direction. Three steering modes are available.
See “Steer Modes” on page 3-19.
4. Frame Level Indicator: Enables the operator to determine the left to right level
condition of the telehandler.
5. Accessory Control Lever (if equipped): See page 3-18.
6. Right Hand Panel: See page 3-17.
7. Boom Joystick: See page 3-12.
8. Frame Level and Attachment Tilt (if equipped) Joystick: See page 3-14.
9. Auxiliary Hydraulic Joystick (G9-43A): See page 3-15.
10. Decompression Valve (G9-43A if equipped): Pull to relieve pressure in auxiliary
hydraulic circuit. See “Hydraulic Operated Attachment” on page 5-12.
11. Accelerator Pedal: Pressing down pedal increases engine and hydraulic speed.
12. Service Brake Pedal: The further the pedal is depressed, the slower the
travel speed.
13. Ignition Switch: Key activated. See page 3-7.
14. Auxiliary Hydraulic Joystick (G6-42A): See page 3-15.
