SECTION 6 - GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE
6-2
– JLG Lift –
3121165
6.1
OPERATING SPECIFICATIONS
Table 6-1. Operating Specifications
Model
1930ES
2030ES
2630ES
2646ES
3246ES
Maximum Stowed Travel Grade (Gradeability)
- Refer to Figure 4-1. on page 4-6
25%
25%
25%
25%
25%
Maximum Stowed Travel Grade (Sideslope)
- Refer to Figure 4-1. on page 4-6
5°
5°
5°
5°
5°
Maximum Platform Height
18.75 ft
5.7 m
20 ft
6 m
25.5 ft
7.75 m
26 ft
7.9 m
32 ft
9.8 m
Maximum Tire Load:
ANSI
CE
1365 lb (620 kg)
1540 lb (699 kg)
1660 (755)
1835 lb (832 kg)
1885 lb (832 kg)
1835 lb (832 kg)
2070 lb (939 kg)
2320 lb (1052 kg)
2070 lb (939 kg)
2320 lb (1052 kg)
Ground Bearing Pressure (ANSI)
109 psi
(7.7 kg/cm
2
)
81 psi
(5.7 kg/cm
2
)
90 psi
(6.3 kg/cm
2
)
87 psi
(6.1 kg/cm
2
)
87 psi
(6.1 kg/cm
2
)
Ground Bearing Pressure (CE)
8.7 kg/cm
2
(123 psi)
6.3 kg/cm
2
(90 psi)
6.3 kg/cm
2
(90 psi)
6.9 kg/cm
2
(98 psi)
6.9 kg/cm
2
(98 psi)
Maximum Drive Speed
3 mph
(4.8 kmh)
3 mph
(4.8 kmh)
2.75 mph
(4.4 kmh)
2.5 mph
(4 kmh)
2.5 mph
(4 kmh)
Maximum Wind Speed
28 mph (12.5 m/s)
(Depending on model, market, and indoor/outdoor selection, see Table 6-2, Platform Capacities on page 6-5)
