SECTION 6 - GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE
6-6
– JLG Lift –
3121165
Dimensional Data
Table 6-3. Dimensions
Model
1930ES
2030ES
2630ES
2646ES
3246ES
Unit of Measure
feet
meter
feet
meter
feet
meter
feet
meter
feet
meter
Platform Height - Elevated
18.75
5.7
20
6
25.5
7.77
26
7.9
31.8
9.7
Platform Height - Stowed
2.9
0.9
3.6
1.1
4
1.2
4
1.2
4
1.2
Working Height
25
7.6
26
7.9
32
9.8
32
9.8
38
11.6
Overall Stowed Machine Height - Rails Up
6.5
2
7.2
2.2
7.7
2.3
7.7
2.3
7.7
2.3
Overall Stowed Machine Height - Rails Collapsed
N/A
N/A
6
1.8
6.4
1.9
6.4
1.9
6.4
1.9
Rail Height (From platform floor)
3.6
1.1
3.6
1.1
3.6
1.1
3.6
1.1
3.6
1.1
Overall Machine Width
2.5
0.8
2.5
0.8
2.5
0.8
3.7
1.2
3.7
1.2
Overall Machine Length - Deck Retracted
6
1.9
7.5
2.3
7.5
2.3
8.2
2.5
8.2
2.5
Overall Machine Length - Deck Extended
9
2.8
10.5
3.2
10.5
3.2
12.4
3.8
12.4
3.8
Platform Size - Length
6.1
1.9
7.5
2.3
7.5
2.3
8.2
2.5
8.2
2.5
Platform Size - Width
2.5
0.8
2.5
0.8
2.5
0.76
3.7
1.1
3.7
1.1
Platform Extension Length
3
0.9
3
0.9
3
0.9
4.2
1.3
4.2
1.3
Wheelbase
63
1.6
73.9
1.9
73.9
1.9
82.3
2
82.3
2
