SECTION 1 - SPECIFICATIONS
1-8 – JLG Lift – 3121105
1.9 CYLINDER SPECIFICATIONS
NOTE: All cylinder dimensions are given in inches (in), with
the metric equivalent, centimeters (cm) in parenthe-
ses.
Table 1-8.Cylinder Specifications
Cylinder Bore Stroke Rod Dia.
Lift 9.0
(22.9)
43.375
(120.3)
4.0
(10.2)
Master Level
(100SX, 110SX) 2.5
(6.4)
14.5
(36.8)
1.25
(3.2)
Master Level
(110SXJ) 2.5
(6.4)
15.1
(38.4)
1.25
(3.2)
Slave Level
(100SX, 110SX) 2.5
(6.4)
13.875
(35.2)
1.25
(3.2)
Slave Level
(110SXJ) 3.5
(8.9)
6.94
(17.6)
1.75
(4.4)
Steer 3
(7.6)
10.31
(26.2)
1.5
(3.8)
Telescope
(100SX, 110SXJ 5
(12.7)
247.81
(629.4)
3.5
(8.9)
Telescope
(110HX) 5
(12.7)
266
(675.6)
3.5
(8.9)
Axle Extension 2.5
(6.4)
28.19
(71.6)
1.25
(3.2)
Extend-a-Reach
(100HX+10) 3.5
(8.9
18.31
(46.5)
2.5
(6.4)
