SECTION 1 - SPECIFICATIONS
3121105 – JLG Lift – 1-1
SECTION 1. SPECIFICATIONS
1.1 CAPACITIES
Engine Crankcase
Deutz F4L912 w/Filter - 13.2 quarts (12.5 liters)
Fuel Tank
26 gallons (98 liters)
Hydraulic Tank
50 gallons (189 liters)
1.2 COMPONENT DATA
NOTE: Tolerance on all engine rpm settings is plus or minus
10%.
Engine - Deutz F4L912
Fuel - Diesel
Oil Capacity (crankcase only) - 12.7 quarts (12 liters)
Low (Mid) RPM - 1800
High RPM - 2400
Alternator - 55 Amp
Battery - 1000 cold cranking Amps, 210 minutes reserve
capacity, 12 VDC
Fuel Consumption
Low RPM - 2.4 gph (9.1 lph)
High RPM - 3.8 gph (14.2 lph)
Horsepower - 70 @ 2400 RPM, no load
Torque Hub
Input Torque - 116 ft. lbs.
Input Speed - 2734 rpm
Output Torque - 10236 ft. lbs.
Output Speed - 31 rpm
Static Brake Torque - 147.5 ft. lbs.
Release Pressure - 261 psi
Max. Release Pressure - 725 psi
Drive Motor
Max. Displacement - 2.75 in 3 (45 cc)
Min. Displacement - 0.93 in
3
(15.2 cc)
Output Speed at Max. Displacement - 3000 rpm
Output speed at Min. Displacement - 4000 rpm
1.3 PERFORMANCE DATA - 100SX, 110SX &
110SXJ
Platform Height
100SX - 100ft. (30.5 m)
110SX & 110SXJ - 110 ft. (33.5 m)
Horizontal Outreach
60 ft. (18.3 m)
Below Ground Reach (110SX only)
12 ft. (3.6 m)
Swing
360° Continuous
Platform Capacity - Restricted (100SX &
110SX only)
1000 lbs. (450 kg)
Platform Capacity - Unrestricted
500 lbs. (230 kg)
Platform Rotator
180° Hydraulic
Jib Range of Articulation - 110SXJ
10 ft. (3.05 m) 95 degrees (+15, -80)
Overall Width - Axles Retracted
8 ft. 2 in. (2.49 m)
Overall Width - Axles Extended
10 ft. 10 in. (3.3 m)
Tailswing (Axles Extended)
2 ft. 10 in. (86 cm)
Stowed Height
10 ft. (3.0 m)
Stowed Length
100SX - 37ft. 10 in. (11.55 m)
110SX - 38 ft. 7 in. (11.76 m)
110SXJ - 44 ft. 2 in. (13.46 m)
