SECTION 1 - SPECIFICATIONS
3121105
– JLG Lift –
1-7
1.7
PRESSURE SETTINGS
Main Valve
Main - 3450 psi (238 bar)
Lift Down - 1500 psi (103 bar)
Jib (Up) - 3000 psi (207 bar)
Jib (Down) - 1400 psi (97 bar)
Swing - 1200 psi (83 bar)
Platform Level Up - 2500 psi (172 bar)
Platform Level Down - 2200 psi (152 bar)
Drive - 4500 psi (310 bar)
Steer - 2850 psi (197 bar)
Platform Rotate - 2500 psi (172 bar)
Extendable Axles In - 2500 psi (172 bar)
Extendable Axles Out - 2500 psi (172 bar)
NOTE: Refer to Section 5 for pressure setting procedures.
1.8
FUNCTION SPEEDS (IN SECONDS)
100SX
Lift Up - 100-85
Lift Down - 100-75
Swing Right & Left - 200-140
Telescope Out - 93-74
Platform Rotate Right & Left - 20-10
Drive (200ft.) - 57-47
Drive above Horizontal (50ft.) - 89-96
110SX
Lift Up - 100-85
Lift Down - 100-75
Swing Right & Left - 200-140
Telescope Out - 100-80
Platform Rotate Right & Left - 20-10
Drive (200ft.) - 57-47
Drive above Horizontal (50ft.) - 89-96
110SXJ
Lift Up - 100-85
Lift Down - 100-75
Swing Right & Left - 200-140
Telescope Out - 93-74
Platform Rotate Right & Left - 24-36
Articulated Jib Up - 15-20
Articulated Jib Down - 45-55
Drive (200ft.) - 56-46
Drive above Horizontal (50ft.) - 89-96
120SXJ
Lift Up - 100-85
Lift Down - 100-75
Swing Right & Left - 200-140
Telescope Out - 100-80
Platform Rotate Right & Left - 24-36
Articulated Jib Up - 15-20
Articulated Jib Down - 45-55
Drive (200ft.) - 56-46
Drive above Horizontal (50ft.) - 89-96
