SECTION 6 - GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE

3121637

– JLG Lift –

6-5

Machine Major Component Weights

Performance

Table 6-7. Major Component Weights

Model

X600AJ

Engine (tank full)

Gasoline: 86 lb. (39 kg)

Lithium Ion Battery Pack (72V)

401 lb. (182kg)

Boom Sections Combined

3,104 lb. (1408 kg)

Lift Cylinders

Level Cylinder:

Jib Cylinder:

3rd boom level cylinder:

Lift cylinder:

Upper lift cylinder:

Swing Actuator:

Telescope cylinder:

17.6 lb. (8 kg)
26.4 lb. (12 kg)
117.5 lb. (53.3 kg)
15.4 lb. (7 kg)
117.5 lb. (53.3 kg)
37.4 lb. (17 kg)
135.5 lb. (61.5 kg)

Platforms

2 - occupant: 79.3 lb. (36 kg)

Chassis

2,802 lb. (1271 kg)

Table 6-8. Function Speeds

FUNCTION

X600AJ

TIME (SECONDS)

Telescope Extend:

Retract:

21 - 28
16 - 20

Tower Boom Up:

Down:

30 - 35
30 - 35

Upper Boom Up:

Down:

35 - 40
35 - 40

Basket Rotate Right:

Left:

7 - 10
7 - 10

Swing Left:

Right:

45 - 50
45 - 50

Jib Up:

Down:

7 -10

7 - 10

Basket Level Up:

Down:

33 - 55
37 - 50
