SECTION 6 - GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE
6-4 – JLG Lift – 3121637
Engine Data Lithium-Ion Specifications
Table 6-5. Honda iGX440 Specifications
Model X600AJ
Type Gasoline/Air cooled
Number of cylinders 1
Displacement 27 cu. in. (440 cm
3
)
Output 12.74 hp (9.5 kW)
High engine speed 3600 RPM
Torque (Max.) 22 ft. lb. / 29.8 Nm @ 2500
RPM
Table 6-6. Lithium Ion Specifications
Model X600AJ
Battery Pack
No. of cells in the battery pack:
Rated voltage of each cell:
Max. cell voltage:
Min. cell voltage:
Features of complete pack:
*Charge cycles:
Cathode:
Anode:
Memory effect:
22 cells
3.2 volt
3.65 volt
2.5 volt
72 volt @ 100 Amp/hr
2000 cycles
Lithium Ion Phosphate (LiFePO
4
)
Graphite
NO
Battery Charger
Type:
Necessary time to recharge:
120 V (+/– 10%) - 50/60 Hz
8 hrs to Balance -
6 hrs. to 80% of recharge
Electric System 72 volt for the batteries -
12 volt for the machine
Electric Motor 72 volt - three phase - 3500 watt
* The charge cycles have to be considered based on the fact that there is not mem-
ory effect in the lithium batteries, i.e. 2000 charges at 100% or 4000 charges at
50%, etc..
