SECTION 6 - GENERAL SPECIFICATIONS AND OPERATOR MAINTENANCE
3121637 – JLG Lift – 6-3
Chassis
Capacities
Table 6-3. Chassis Data
Model X600AJ
Maximum Travel Grade w/ boom in stowed position
(gradeability) 15° (26%)
Maximum Travel Side Slope w/ boom in stowed
position 12° (21%)
Turning radius 0°
Maximum ground pressure per track (psi) 9.2 psi (0.64 daN/cm
2
)
Maximum ground pressure per outrigger 45 psi (3.04 daN/cm
2
)
Maximum outrigger pad load (per pad) 4,833 ft-lb. (2,150 daN)
Outrigger pad diameter 11.8 in (300 mm)
Max drive speed (Gas Engine)
w/ 2nd Speed 0.31 mph (0.5 km/hr)
0.81 mph (1.3 km/hr)
1.55 mph (2.5 km/hr)
Max hydraulic system pressure
Track/Outrigger:
Boom:
2,393 psi (165 bar)
2,683 psi (185 bar)
Maximum wind speed 28 mph (12.5m/s)
Maximum manual force 90 lb. (400 N)
Electrical system voltage
Charger/Platform Plug - AC:
Gasoline Engine/Start Battery/System - DC:
Lithium-Ion Battery Pack/Electric Motor:
120V
12V
72V
Gross machine weight (platform empty)
Gas Engine:
72V Lithium-Ion:
6,350 lb. (2880 kg)
6,571 lb. (2980 kg)
Table 6-4. Capacities
Model X600AJ
Hydraulic Tank 10.56 gal. (40 L)
Fuel Tank Gasoline: 1.55 gal. (5.9 L)
Engine Oil Gasoline: 0.3 gal. (1.1 L)
