SECTION 6 - JLG CONTROL SYSTEM
3121200
– JLG Lift –
6-33
DRIVE LEFT FWD SOLENOID
- SHORT TO BATTERY
120
3-3
9
DRIVE LEFT FWD SOLENOID
- SHORT TO GROUND
121
3-3
9
DRIVE LEFT FWD SOLENOID
- OPEN CIRCUIT
122
3-3
9
DRIVE LEFT REV SOLENOID -
SHORT TO BATTERY
123
3-3
9
DRIVE LEFT REV SOLENOID -
SHORT TO GROUND
124
3-3
9
DRIVE LEFT REV SOLENOID -
OPEN CIRCUIT
125
3-3
9
DRIVE RIGHT FWD SOLE-
NOID - SHORT TO BATTERY
126
3-3
9
DRIVE RIGHT FWD SOLE-
NOID - SHORT TO GROUND
127
3-3
9
DRIVE RIGHT FWD SOLE-
NOID - OPEN CIRCUIT
128
3-3
9
DRIVE RIGHT REV SOLE-
NOID - SHORT TO BATTERY
129
3-3
9
DRIVE RIGHT REV SOLE-
NOID - SHORT TO GROUND
130
3-3
9
DRIVE RIGHT REV SOLE-
NOID - OPEN CIRCUIT
131
3-3
9
DRIVE ENABLE SOLENOID -
SHORT TO BATTERY
132
3-3
9
DRIVE ENABLE SOLENOID -
SHORT TO GROUND
133
3-3
9
DRIVE ENABLE SOLENOID -
OPEN CIRCUIT
134
3-3
9
POWER MODULE TOO HOT –
PLEASE WAIT
135
4-2
4
Lift Up, Swing Left, Swing Right, Tele-
scope In, Telescope Out, Jib Up, Level
Up, Level Down, Front Left L/J, Front
Right L/J, Rear Left L/J, Rear Right L/
J, Set (Extend L/J), Stow (Retract L/J)
Lift Up, Swing Left, Swing Right, Tele-
scope In, Telescope Out, Jib Up, Level
Up, Level Down, Front Left L/J, Front
Right L/J, Rear Left L/J, Rear Right L/
J, Set (Extend L/J), Stow (Retract L/J)
Table 6-5. Help Messages
Help Message
Index
Service
Flash
Code
User
Flash
Code
Function in Creep Mode
Function Locked Out from
Ground Control
Function Locked Out from
Platform Control
