SECTION 6 - JLG CONTROL SYSTEM
6-28
– JLG Lift –
3121200
FUNCTION PROBLEM – LIFT
UP PERMANENTLY
SELECTED
34
2-3
1
Lift Up
FUNCTION PROBLEM – LIFT
DOWN PERMANENTLY
SELECTED
35
2-3
1
Lift Down
FUNCTION PROBLEM –
SWING LEFT PERMANENTLY
SELECTED
36
2-3
1
Swing Left
FUNCTION PROBLEM –
SWING RIGHT PERMA-
NENTLY SELECTED
37
2-3
1
Swing Right
LIFT DOWN PREVENTED –
TELE IN FIRST
38
2-5
2
Lift Down
Lift Down
TELE OUT PREVENTED –
SET LEVELING JACKS
39
2-5
2
Telescope Out
Telescope Out
TELE OUT PREVENTED –
TILTED
40
2-5
2
Telescope Out
Telescope Out
LIFT UP & TELE OUT PRE-
VENTED – TILTED & ABOVE
ELEVATION
41
2-5
2
Lift Up, Telescope Out
Lift Up, Telescope Out
LIFT UP & TELE OUT PRE-
VENTED – UNSET & ABOVE
ELEVATION
42
2-5
2
Lift Up, Telescope Out
Lift Up, Telescope Out
LIFT UP & TELE OUT
PREVENTED – TILTED,
UNSET & ABOVE ELEVATION
43
2-5
2
Lift Up, Telescope Out
Lift Up, Telescope Out
LIFT UP PREVENTED – LIFT
DOWN THEN SET LEVELING
JACKS
44
2-5
2
Lift Up
Lift Up
LIFT UP PREVENTED –
STOW LEVELING JACKS
45
2-5
2
Lift Up
Lift Up
LIFT UP PREVENTED –
TILTED
46
2-5
2
Lift Up
Lift Up
LEVELING JACKS
PREVENTED – ELEVATED
47
2-5
2
Set (Extend L/J)
Set (Extend L/J)
LEVELING JACK STOW
PREVENTED – TELE IN FIRST
48
2-5
2
Stow (Retract L/J)
Stow (Retract L/J)
Table 6-5. Help Messages
Help Message
Index
Service
Flash
Code
User
Flash
Code
Function in Creep Mode
Function Locked Out from
Ground Control
Function Locked Out from
Platform Control
