SECTION 6 - JLG CONTROL SYSTEM
3121200
– JLG Lift –
6-27
FUNCTION PROBLEM – LIFT
UP AND DOWN BOTH
SELECTED
22
2-3
9
Lift Up, Lift Down
FUNCTION PROBLEM –
SWING LEFT AND RIGHT
BOTH SELECTED
23
2-3
9
Swing Left, Swing Right
FUNCTION PROBLEM –
ENGINE CHOKE PERMA-
NENTLY SELECTED
24
2-3
1
Engine Choke Pull, Engine Choke Hold Engine Choke Pull, Engine Choke Hold
FUNCTION PROBLEM –
ENGINE START PERMA-
NENTLY SELECTED
25
2-3
1
Engine Start, Engine Throttle Pull,
Engine Throttle Hold
Engine Start, Engine Throttle Pull,
Engine Throttle Hold
FUNCTION PROBLEM –
LEVEL UP PERMANENTLY
SELECTED
26
2-3
1
Level Up
FUNCTION PROBLEM –
LEVEL DOWN PERMA-
NENTLY SELECTED
27
2-3
1
Level Down
FUNCTION PROBLEM –
TELESCOPE IN PERMA-
NENTLY SELECTED
28
2-3
1
Telescope In
FUNCTION PROBLEM –
TELESCOPE OUT PERMA-
NENTLY SELECTED
29
2-3
1
Telescope Out
FUNCTION PROBLEM – JIB
UP PERMANENTLY
SELECTED
30
2-3
1
Jib Up
FUNCTION PROBLEM – JIB
DOWN PERMANENTLY
SELECTED
31
2-3
1
Jib Down
FUNCTION PROBLEM – LEV-
ELING JACK SET PERMA-
NENTLY SELECTED
32
2-3
1
Set (Extend L/J)
FUNCTION PROBLEM – LEV-
ELING JACK STOW PERMA-
NENTLY SELECTED
33
2-3
1
Stow (Retract L/J)
Table 6-5. Help Messages
Help Message
Index
Service
Flash
Code
User
Flash
Code
Function in Creep Mode
Function Locked Out from
Ground Control
Function Locked Out from
Platform Control
