Truss boom, Truss boom -5 – JLG 4009 Suspended Load Supplement Operator Manual User Manual
Page 41

Section 4 - Attachments
4-5
31200487
Truss Boom
Description
P/N
Truss Boom 2 m - 4000 kg.........................................1001101442
Use Truss Boom Capacity Chart
Suspend loads in accordance with requirements set forth in Section
1 - General Safety Practices.
The joystick (1) controls movement of the boom.
The attachment tilt roller switch (2) controls truss boom tilt.
• Push roller switch down to tilt up.
• Push roller switch up to tilt down.
