Section 2 - Load Management Indicator System (LMIS)
2-8
31200487
Pressure Values
The third menu displays Pressure Values.
In this menu the following values are shown:
• P - Differential pressure of the Lift cylinder (bar).
• L - Pressure in the piston side of the Lift cylinder (bar).
• H - Pressure in the rod side of the Lift cylinder (bar).
• p - Differential pressure in the Compensation cylinder (bar).
• l - Pressure in the piston side of Compensation cylinder (bar).
• h - Pressure in rod side of the Compensation cylinder (bar).
Angle and Length Transducers
The fourth menu displays information from the cable reel.
In this menu the following values are shown:
• A - Angle Reading from angle sensor.
• L - Length Reading from length sensor.
• E - Error reading from cable reel.
P03 : Pressures
P XXX L XXX H XXX
p XXX l XXX
h XXX
P04 : Act 1A
Act1A
A : XXX
E : XX
L : XXX
