Section 2 - Load Management Indicator System (LMIS)
2-7
31200487
2.4
DIAGNOSTIC DATA
By pressing ENT, the display shows sub-menus. To enter a sub-menu, wait 2-3
seconds on the selected menu.
Alarms and Warnings
The first menu displays the Alarm and Warning Codes.
In this menu, the Alarm code and Warning codes are shown. See page 5-2 for listing
of codes.
LMI Values
The second menu displays the LMI Values.
In this menu the following values are shown:
• P - Differential Pressure (bar).
• W - Weight Lifted (ton).
• M - Max Load (ton).
• Ac - Boom Angle (degree).
• L - Boom Length (meter).
• R - Boom Radius (meter).
P01 : Alarms
Alarms :
XXXX
Warning :
XXXX
P02 : Lmi Values
P XXX W XXX M XXX
Ac XXX L XXX R XXX
