Passenger Side Installation Pictured
















Cut out a 1-1/4” wide x 4” long
slot in each splash guard to
clear the Mounting Brackets

Cut out (2) 3/4” wide slots in the spoiler

(3) 12mm x 30mm Hex Bolts
(3) 12mm Flat Washers
(3) 12mm Nylon Lock Nuts

10mm x 25mm Button
Head Bolt
10mm Flat Washers
10mm Nylon Lock Nut

Installation Complete

Fig 10

Fig 11

Fig 12A

Fig 12B

Replace factory hardware
for this mounting location
with the included:
6mm x 30mm Phillips
Screw
6mm Lock Washer
6mm Flat Washer

Replace factory hardware
for this mounting location
with the included:
6mm x 30mm Phillips
Screw
6mm Lock Washer
6mm Flat Washer

Front

Front

Front

Front

Page 5 of 5

10/29/13
