Aries Automotive 3062-2 User Manual
Page 4
Passenger Side Installation Pictured
2008 Models
(2) 10mm x 30mm Hex Bolts
(2) 10mm Lock Washers
(2) 10mm Flat Washers
2009-2010 Models
(2) 8mm Threaded Inserts
(2) 8mm x 30mm Hex Bolts
(2) 8mm Lock Washers
(2) 8mm Flat Washers
Remove this
plastic fastener
8mm x 25mm
Bolt Plate
Bolt Plate
8mm Flat Washer
8mm Nylon Lock Nut
10mm Rod Bolt
10mm Lock Washer
10mm Flat Washer
10mm Nylon Lock Nut
Fig 5
Fig 6
Fig 7
Fig 8
Fig 9
Page 4 of 5
10/29/13
