GRILLE GUARD
09-2013 RAM 1500
Page 3 of 6 6/4/12 (DP)
To protect your investment, wax this product after installing. Regular waxing is recommended to add a protective layer
over the finish. Do not use any type of polish or wax that may contain abrasives that could damage the finish.
For stainless steel: Aluminum polish may be used to polish small scratches and scuffs on the finish. Mild soap may be
used also to clean the Grille Guard.
For gloss black finishes: Mild soap may be used to clean the Grille Guard
Driver Side Installation Pictured
Pry up the center pin to
remove the complete fastener
(Fig 1A) Pictured from behind bumper
Fig 1B
Pin
Housing
(Fig 2) Driver side pictured from behind
bumper (non tow hook models)
Front
For illustration only, clips
may differ depending on
model and year
Remove the (2) factory hex nuts
from the lower bumper bolts
(Fig 3) Driver side Brackets Pictured
(non tow hook models)
Front
Driver/Left
Support Bracket
Driver/Left
Mounting Bracket
Driver/Left Frame Bracket
(no tow hook models)
