Chapter 11 – Troubleshooting
58 TB80/TB85J Fixed Axle – 0112823EE
Symptom
Engine will not start from
lower controls.
Engine will not start from
upper controls.
Possible Cause
Switches are set wrong. The engine
will not crank.
The controls selector switch was left
in the lower control position for 30
seconds or longer before starting
the engine.
The main system circuit breaker on
the wiring box has tripped. The en-
gine will not crank.
Switches are set wrong. The engine
will not crank.
Platform foot switch is activated.
The master start switch was left in
the on position for 30 seconds or
longer before turning it to start.
The main system circuit breaker on
the upper control panel or the wir-
ing box has tripped. The engine will
not crank.
Corrective Action
Turn the battery disconnect switch on
and then at the lower controls:
• Pull the emergency stop button
outward.
• Place the controls selector switch
in the lower control position.
• Wait for 5 seconds and then
press the start button to start.
Press the start button within 30 sec-
onds of placing the controls selector
in the lower controls position.
Push the main system circuit breaker
button back in. If the button pops back
out, refer the problem to a qualified
service technician.
Turn the battery disconnect switch on
and then at the lower controls:
• Pull the emergency stop button
outward.
• Place the controls selector
switch in the upper controls po-
sition.
• Wait for 5 seconds and then
press the start button to start.
From the upper controls:
• Turn the master start switch off.
• Pull the emergency stop button
outward.
• Place the master start switch in
the on position for 5 seconds and
then turn the switch to start.
Do not step on foot switch while start-
ing the engine.
Turn the master start switch back to
off, then to start within 30 seconds.
Push the main system circuit breaker
button back in. If the button pops back
out, refer the problem to a qualified
service technician.
