Chapter 2 – Specifications

TB80/TB85J Fixed Axle – 0112823EE

7

General Specifications – TB80

Aerial Platform
Working height

26.2 m (86

)

Maximum platform height

24.4 m (80

)

Horizontal reach

21.7 m

(71

1

1

/

2

)

Main boom
Articulation

-13.5° to +70°

Extension

13.4 m (44

)

Turntable rotation

360° continuous

Turning radius, 4 wheel steer

2.4 m

(7

10)

Wheelbase

3 m (10

)

Ground clearance

33 cm (13

)

Maximum wheel load

8,375 kg (18,425 lbs)

Maximum ground pressure

6.6 kg/cm² (94 psi)

Weight, EVW
Approximate

16,480 kg (36,250 lbs)

Width

2.5 m (8

6

)

Stowed length

11.8 m

(38

10)

Stowed height

2.9 m (9

7

)

Platform
Dimensions
Standard Steel

76 cm x 244 cm (30

x 92

)

Optional Steel

76 cm x 152 cm (30

x 60

)

Optional Aluminum

76 cm x 152 cm (30

x 60

)

Optional Aluminum

76 cm x 244 cm

(30

x 92)

Rated work load
Steel 30

x 92

227 kg (500 lb)

Steel 30

x 60

272 kg (600 lb)

Aluminum 30

x 60

294 kg (650 lb)

Aluminum 30

x 92

272 kg (600 lb)

Rotation

165 degrees

Maximum number of occupants

2 people

Optional AC generator

110 V

Optional AC generator

220 V

Optional AC generator

220 V, 3-phase, 12 kw

Optional Welder

Function Speed
Turntable rotation
Booms retracted

142 seconds minimum

Booms extended

195 seconds minimum

Main boom
Up

105 seconds minimum

Down

105 seconds minimum

Extend

80 to 90 seconds

Retract

60 to 70 seconds

Platform rotation

16 to 20 seconds

Drive
High, booms stowed

4.8 km/h (3.0 mph)

Mid, booms stowed

2.4 km/h (1.5 mph)

Low, booms raised/extended

1 km/h (0.6 mph)

Drive System
Standard

Four wheel drive

Gradeability – theoretical

45%

Tires
Foam filled

15-625NHS, 16 ply

Electrical System
Voltage

12 V DC negative chassis ground

Source
Gas engine

One -12 V 550 CCA battery

Diesel engine

Two - 12 V 550 CCA batteries

Fluid recommended

distilled water

Hydraulic System
Maximum pressure

19,305 kPa (2,800 psi)

Reservoir capacity

151 l (40 US gal)

System capacity

246 l (65 US gal)

Maximum operating temperature

93°C (200°F)

Hydraulic fluid recommended
Above -13°C (10°F)

Mobil DTE-13M (ISO VG32)

Below -13°C (10°F)

Mobil DTE-11M (ISO VG15)

Engine
Diesel

Cummins B3.3

Diesel

Deutz F4L-2011F

Gasoline and/or LPG

General Motors 2.4

Fuel Tank Capacity
Gasoline or diesel

204 l (54 US gal)

LPG

19.7 kg (43.5 lbs)

Dual fuel gasoline

204 l (54 US gal)

Dual fuel LPG

19.7 kg (43.5 lbs)

Ambient Air Temperature Operating Range
Celsius

-18°C to 43°C

Fahrenheit

0°F to 110°F

Maximum Wind Speed
Gust or steady

45 km/h (28 mph)

Vibration

less than 2.5 m/sec

2

Sound Threshold

below 97 dB(A)
