Chapter 2 – Specifications
4 S2646/S3246 – 0410063EE
General Specifications S2646
Aerial Platform
Working height
9.75 m (32
′
)
Maximum platform height 7.9 m (26
′
)
Turning radius
Inside
25.4 cm (10 ″ )
Outside 2.5 m (101 ″ )
Wheelbase 1.9 m (75
″
)
Ground clearance
Pothole protector raised
10.1 cm (4
″
)
Pothole protector lowered 2.5 cm (1
″
)
Maximum wheel load 1125 kg (2,480 lbs)
Maximum ground pressure 11.7 kg/cm² (166 psi)
Weight, GVW
Approximate
2359 kg (5,200 lbs)
Stowed width 116.8 cm (46
″
)
Stowed length 254 cm (100
″
)
Stowed height
Guardrails raised
236.2 cm (93
″
)
Guardrails lowered 167.6 cm (66 ″ )
Platform
Dimensions
Main
114.3 cm x 238.7 cm (45
″
x 94
″
)
Extension 104.1 cm x 91.4 cm (41
″
x 36
″
)
Total length with extension 330.2 cm (130 ″ )
Rated work load
Total
453.5 kg (1,000 lb)
Extension 113.3 kg (250 lb)
Maximum number of occupants
Outside
1 person
Inside 3 people
Function Speed
Platform raise
25 to 35 seconds
Platform lower 50 to 60 seconds
High drive
Platform lower than 2.1 to 2.4 m (7 to 8 feet)
3.2 km/h (0 to 2 mph)
Low drive
Platform higher than 2.1 to 2.4 m (7 to 8 feet)
0.8 km/h (0 to 0.5 mph)
Drive System
Standard
Two wheel drive
Gradeability 25%
Maximum drive height 10.9 m (26
′
)
Drive/Lift Level Sensor Interlock
Side-to-side
2 degrees
Front-to-rear 4 degrees
Tires
Nonmarking solid rubber 40.6 cm x 12.7 cm (16
″
x 5
″
)
Electrical System
Voltage
24 V DC negative chassis ground
Source Four - 6 V 240 amp hour batteries
Fluid recommended distilled water
Charger 40 amp
Hydraulic System
Maximum pressure
21,373.75 kPa (3,100 psi)
Reservoir capacity 34 l (9 US gal)
System capacity 35 l (9.25 US gal)
Maximum operating temperature 71°C (160°F)
Hydraulic fluid recommended
Above -13°C (10°F)
Mobil DTE-13M (ISO VG32)
Below -13°C (10°F) Mobil DTE-11M (ISO VG15)
Ambient Air Temperature Operating Range
Celsius
-18°C to 43°C
Fahrenheit 0°F to 110°F
Maximum Wind Speed
Gust or steady
12.5 m/s (28 mph)
Vibration less than 2.5 m/sec 2
Sound Threshold below 70 dB(A)
