Chapter 2 – specifications, Component identification – Snorkel S3246 CE User Manual
Page 7
S2646/S3246 – 0410063EE
3
Chapter 2 – Specifications
Component Identification
Chassis
Battery Charger
Upper Controls
Platform
Platform Extension Deck
Left Side
Battery Tray
Battery Disconnect
Switch
Pothole Protector Skid
Operator’s
Manual
Scissors
Structure
Guardrails
Toeboards
Entry Step
Ground Strap
Right Side
Rear
Front
Lower Controls
Hydraulic Tray
Lifting Lugs
Tie-down Lugs
Drive and Steer
Wheels
Drive and Steer
Wheels
Forklift
Pockets
Lifting Lugs
Emergency
Lowering
Handle
Tie-down Lugs
