Meets or exceeds all applicable requirements of
OSHA and ANSI A92.6-1999
Refer to Service Manual for complete parts and
service information.
* Specifications subject to change without notice.
Hot weather orheavy use may reduce performance.
ITEM
Platform Size
w/ Extension
Max. Platform Capacity
Standard w/ Extension
on Extension
Max. No. of occupants
Standard
on Extension
Height
Working Height
Max. Platform Height
Min. Platform Height
Dimensions
Weight
Overall Width
Overall Height
Overall Length
Driveable Height
Surface Speed
Platform Lowered
Platform Raised
Energy Source
System Voltage
Battery Charger
Battery Duty Cycle
Hydraulic Tank Capacity
Maximum Hydraulic
System Pressure
Lift System
Control System
Drive System
Tires
Parking Brake
Turning Radius
Maximum Gradeability
Wheel Base
Guardrails
Toeboard
X20W
44 in. x 87 in. [1.12 m x 2.21 m]
Inside Toeboards
1000 lbs. [453 kg]
250 lbs. [110 kg]
4 people
1 person
26 ft. [7.9 m]
20 ft. [6.1 m]
39 in. [.99 m]
4,273 lbs. [1858 kg]
48 in. [1.22 m]
79 in. [2.0 m]
92 in. [2.34 m]
20 ft. [6.1 m]
0 to 2.3 mph [0 to 3.70 km/h]
0 to .7 mph [0 to 1.13 km/h]
24 Volt Battery Pack (4-220 Amp
Hour, 6 Volt Batteries, min. wt.
62 lbs. each [28.12 kg]), 4 HP
DC Electric Motor
24 Volt DC
25 AMP, 60 Hz 110 VAC
25% for 8 Hours
4 Gallons [15.2 l]
2600 psi [179 Bar]
Three stage scissor assembly
actuated by one Single Stage
Lift Cylinder
Smooth one hand joystick with
two speed operation
Dual Front Wheel Hydraulic Motors
with series or parallel operation
15 in. [381 mm] Diameter Solid
Rubber, non-marking
Spring Applied, Hydraulic Release
Brake with Manual Release
8 in. [254 mm] Inside
23% [13 degrees]
74
3 /
4
in. [1.9 m]
40 in. [1.02 m]
6 in. [152 mm] High
X26N
44 in. x 87 in. [1.12 m x 2.21 m]
Inside Toeboards
1000 lbs. [453 kg]
250 lbs. [110 kg]
4 people
1 person
32 ft. [9.75 m]
26 ft. [7.92 m]
43 in. [1.09 m]
4,747 lbs. [2072 kg]
48 in. [1.22 m]
83 in. [2.11 m]
92 in. [2.34 m]
26 ft. [7.93 m]
0 to 2.3 mph [0 to 3.70 km/h]
0 to .7 mph [0 to 1.13 km/h]
24 Volt Battery Pack (4-220 Amp
Hour, 6 Volt Batteries, min. wt.
62 lbs. each [28.12 kg]), 4 HP
DC Electric Motor
24 Volt DC
25 AMP, 60 Hz 110 VAC
25% for 8 Hours
4 Gallons [15.2 l]
2600 psi [179 Bar]
Four stage scissor assembly
actuated by one Single Stage
Lift Cylinder
Smooth one hand joystick with
two speed operation
Dual Front Wheel Hydraulic Motors
with series or parallel operation
15 in. [381 mm] Diameter Solid
Rubber, non-marking
Spring Applied, Hydraulic Release
Brake with Manual Release
8 in. [254 mm] Inside
22% [12 degrees]
74
3 /
4
in. [1.9 m]
40 in. [1.02 m]
6 in. [152 mm] High
Specifications*
Safety
Rules
and
Operating
Instructions
Safety
Rules
and
Operating
Instructions
X20N
28in. x 87 in. [711 mm x 2.21 m]
Inside Toeboards
750 lbs. [340kg]
250 lbs. [110 kg]
3 people
1 person
26 ft. [7.9 m]
20 ft. [6.1 m]
38 in. [.97 m]
3,828 lbs. [1656 kg]
32 1 /
2
in. [.83m]
78 in. [1.98m]
92 in. [2.34m]
20 ft. [6.1 m]
0 to 2.3 mph [0 to 3.70 km/h]
0 to .7 mph [0 to 1.13 km/h]
24 Volt Battery Pack (4-220 Amp
Hour, 6 Volt Batteries, min. wt.
62 lbs. each [28.12 kg]), 4 HP
DC Electric Motor
24 Volt DC
25 AMP, 60 Hz 110 VAC
25% for 8 Hours
4 Gallons [15.2 l]
2400 psi [165 Bar]
Three stage scissor assembly
actuated by one Single Stage
Lift Cylinder
Smooth one hand joystick with
two speed operation
Dual Front Wheel Hydraulic Motors
with series operation
15 in. [381 mm] Diameter Solid
Rubber, non-marking
Spring Applied, Hydraulic Release
Brake with Manual Release
8 in. [254 mm] Inside
23% [13 degrees]
74
3 /
4
in. [1.9 m]
40 in. [1.02 m]
6 in. [152 mm] High
X31N
44 in. x 87 in. [1.12 m x 2.21 m]
Inside Toeboards
700 lbs. [318 kg]
250 lbs. [110 kg]
3 people
1 person
37 ft. [11.28 m]
31 ft. [9.44 m]
43 in. [1.09 m]
5430 lbs. [2463 kg]
48 in. [1.22 m]
83 in. [2.11 m]
92 in. [2.34 m]
31 ft. [7.93 m]
0 to 2.3 mph [0 to 3.70 km/h]
0 to .7 mph [0 to 1.13 km/h]
24 Volt Battery Pack (4-220 Amp
Hour, 6 Volt Batteries, min. wt.
62 lbs. each [28.12 kg]), 4 HP
DC Electric Motor
24 Volt DC
25 AMP, 60 Hz 110 VAC
25% for 8 Hours
5 Gallons [19 l]
2000 psi [138 Bar]
Five stage scissor assembly
actuated by two Single Stage
Lift Cylinders
Smooth one hand joystick with
two speed operation
Dual Front Wheel Hydraulic Motors
with series or parallel operation
15 in. [381 mm] Diameter Solid
Rubber, non-marking
Spring Applied, Hydraulic Release
Brake with Manual Release
8 in. [254 mm] Inside
20% [11 degrees]
74
3 /
4
in. [1.9 m]
40 in. [1.02 m]
6 in. [152 mm] High
