Introduction
107098-002 TM12 - Operator Manual Page 3
I NTRODUCTION
This manual covers the TM12 Aerial Work Platform. This manual must be stored on the machine at all
times.
Read, understand and follow all safety rules and operating instructions before attempting to operate the
machine.
G ENERAL D ESCRIPTION
Figure 1: TM12 Series
W A R N I N G ! !
DO NOT use the machine if all guardrails
are not properly in place and secured with
all fasteners properly torqued.
1. Platform
2. Entry Chain
3. Elevating Mast
4. Platform Controls
5. Manual Case
6. Electrical Box
7. Hydraulic Reservoir
8. Battery Tray
9. Emergency Down Valve Knob
10. Battery Charger
11. Charger Outlet Plug
4
6
7
8
10
11
1
2
3
5
9
