Labels
L ABELS
These labels shall be present and in good condition before operating the machine. Be sure to read, under-
stand and follow these labels when operating the machine.
1 060197-000
2 066552-000
3 061205-005
5 005221-000
6 005223-005
7 .066554-000
8 107050-000
10 101250-000
13 010076-001
15 065568-001
19 062562-001
20 066550-001
21 014222-003-99
22 061220-002
23 066555-000
24 066568-000
25 066556-000
26 066522-000
27 101252-000
28 066556-001
29 107051-000
HYDRAULIC FLUID
060197-000
BATTERY
MAINTAIN BATTERY FLUID
AT RECOMMENDED LEVEL
EMERGENCY
STOP
LIFT DRIVE
NEUTRAL
UpRight
FORWARD
UP
DOWN
REVERSE
CUTOUT CUTOUT
EMERGENCY
STOP
UP
DOWN DECK
OFF
CHASSIS
BREAKER
CIRCUIT
TIP-OVER HAZARD
DANGER !
BATTERIES ACT AS COUNTERWEIGHT
60 LBS OR MORE
EACH REPLACEMENT BATTERY SHALL WEIGH
TIP-OVER HAZARDS
ELECTROCUTION HAZARD
FALL HAZARD
slopes or soft ground. DO NOT elevate or drive elevated on
drop offs DO NOT drive into holes or over
lines. THIS MACHINE IS NOT INSULATED.
DO NOT operate within ten feet of power
wires.
Look up, down and around for electrical
DO NOT climb on guardrail.
Make sure guardrails are fastened securely
Secure gate or chain across enterance.
DO NOT use ladders or scaffolding on platform
DO NOT climb down mast.
! DANGER
serious injury.
rules will cause death or
and obey the following safety
Failure to read, understand,
! WARNING
CRUSHING HAZARD
SERVICING MACHINE
COMPLETELY BEFORE
LOWER PLATFORM
PLATFORM
KEEP CLEAR OF
CHARGER
BATTERY
