Specifiche
500315-005
TL38 - Manuale dell'operatore
Pagina 15
S
PECIFICHE
*Le specifiche sono soggette a modifica senza preavviso. Un clima molto caldo o un utilizzo
particolarmente intenso potrebbero compromettere le prestazioni.
Fare riferimento al manuale di assistenza per informazioni complete sui componenti e la manutenzione.
Questa macchina soddisfa o supera tutti i requisiti delle direttive CE e GS sulla sicurezza dei macchinari.
ITEM
MANUAL OUTRIGGERS
HYDRAULIC OUTRIGGERS
Duty Cycle
30% of 8 hour cycle
30% of 8 hour cycle
Platform Size
0.7m x 1.3m[2.3ft x 4.3ft] (inside guardrails) 0.7m x 1.3m [2.3ft x 4.3ft] (inside guardrails)
Max. Platform Capacity
215kg [473lbs]
215kg [473lbs]
Max. # of Occupants
2 People
2 People
Height
Maximum Working Height
13.45m [44.1ft]
13.49m [44.3ft]
Maximum Platform Height
11.45m [38ft]
11.49m [38ft]
Min. Platform Height
0.65m [2.1ft]
0.65m [2.1ft]
Max. Working Outreach
6m [19.7ft]
6m [19.7ft]
Travelling Dimensions:
Length
6.08m [19.9ft]
6.08m [19.9ft]
Width
1.53m [5.0ft]
1.53m [5.0ft]
Height
2.00m [6.6ft]
2.00m [6.6ft]
Outrigger Spread
(front-rear x side-side)
(front-rear x side-side)
Max. Clearance
3.40m x 3.42m [11.2ft x 11.2ft]
3.39m x 3.45m [11.1ft x 11.3ft] *
3.46m x 3.56m [11.4ft x 11.7ft]**
Min. Effective Clearance
3.25m x 3.27m [10.7ft x 10.7ft]
3.16m x 3.22m [10.4ft x 10.6ft]*
3.24m x 3.33m [10.6ft x 10.9ft]**
Rotation
370 degrees non-continuous
370 degrees non-continuous
Gross Weight
1468kg [3,237lbs]
1468kg [3,237lbs]
Maximum Towable Speed
83km/h [50mph]***
83km/h [50mph]***
Power Source
24V DC 4HP, 4 X 6V 220Ah Batteries
24V DC 4HP, 4 X 6V 220Ah Batteries
System Voltage
24V DC
24V DC
Battery Charger
24V 25A 220/110VAC 50/60 Hz
24V 25A 220/110VAC 50/60 Hz
Hydraulic TankCapacity
15 Litres [3.9 Gallons US]
15 Litres [3.9 Gallons US]
Max. Hydraulic Pressure
155 Bar [2,250psi]
155 Bar [2,250psi]
Hydraulic Oil
ISO #46
ISO #46
Lift System
2 Double Acting Lift Cylinders With
2 Double Acting Lift Cylinders With
Lock Valves And Manual
Lock Valves And Manual
Emergency Lowering Facility.
Emergency Lowering Facility.
1 Double Acting Lift (Jib) Cylinder
1 Double Acting Lift (Jib) Cylinder
Control System
One handed Proportional Joystick
One handed Proportional Joystick
Operating Energy Efficient Motor
Operating Energy Efficient Motor
Control System.
Control System.
Tyres
185 R13 6PLY
185 R13 6PLY
Brake System
Automatic Reverse & Overrun Brakes
Automatic Reverse & Overrun Brakes
Handbrake
Handbrake
Maximum Continuous Sound
Pressure Level At Operation
Stations
74.6 dB(A)
74.6 dB(A
* Outriggers Deployed at full height = Minimum footprint
** Outriggers Deployed at min. height = Maximum footprint
*** Subject to local regulations
