Technische Daten 500315-005
TL38 Betriebsanleitung Seite 15
T
ECHNISCHE
D
ATEN
*Änderungen an den technischen Daten ohne vorherige Ankündigung vorbehalten. Wetter mit hohen
Temperaturen oder eine starke Beanspruchung der Arbeitsbühne kann sich auf die Leistung der Maschine
auswirken.
Umfassende Informationen zu Ersatzteilen und Wartung finden Sie im Wartungshandbuch.
Diese Maschine erfüllt alle Anforderungen der einschlägigen CE- und GS-Maschinenrichtlinien
bzw. übertrifft diese sogar.
ITEM MANUAL OUTRIGGERS HYDRAULIC OUTRIGGERS
Duty Cycle 30% of 8 hour cycle 30% of 8 hour cycle
Platform Size 0.7m x 1.3m[2.3ft x 4.3ft] (inside guardrails) 0.7m x 1.3m [2.3ft x 4.3ft] (inside guardrails)
Max. Platform Capacity 215kg [473lbs] 215kg [473lbs]
Max. # of Occupants 2 People 2 People
Height
Maximum Working Height
13.45m [44.1ft] 13.49m [44.3ft]
Maximum Platform Height 11.45m [38ft] 11.49m [38ft]
Min. Platform Height 0.65m [2.1ft] 0.65m [2.1ft]
Max. Working Outreach 6m [19.7ft] 6m [19.7ft]
Travelling Dimensions:
Length
6.08m [19.9ft] 6.08m [19.9ft]
Width 1.53m [5.0ft] 1.53m [5.0ft]
Height 2.00m [6.6ft] 2.00m [6.6ft]
Outrigger Spread (front-rear x side-side) (front-rear x side-side)
Max. Clearance 3.40m x 3.42m [11.2ft x 11.2ft] 3.39m x 3.45m [11.1ft x 11.3ft] *
3.46m x 3.56m [11.4ft x 11.7ft]**
Min. Effective Clearance 3.25m x 3.27m [10.7ft x 10.7ft] 3.16m x 3.22m [10.4ft x 10.6ft]*
3.24m x 3.33m [10.6ft x 10.9ft]**
Rotation 370 degrees non-continuous 370 degrees non-continuous
Gross Weight 1468kg [3,237lbs] 1468kg [3,237lbs]
Maximum Towable Speed 83km/h [50mph]*** 83km/h [50mph]***
Power Source 24V DC 4HP, 4 X 6V 220Ah Batteries 24V DC 4HP, 4 X 6V 220Ah Batteries
System Voltage 24V DC 24V DC
Battery Charger 24V 25A 220/110VAC 50/60 Hz 24V 25A 220/110VAC 50/60 Hz
Hydraulic TankCapacity 15 Litres [3.9 Gallons US] 15 Litres [3.9 Gallons US]
Max. Hydraulic Pressure 155 Bar [2,250psi] 155 Bar [2,250psi]
Hydraulic Oil ISO #46 ISO #46
Lift System 2 Double Acting Lift Cylinders With 2 Double Acting Lift Cylinders With
Lock Valves And Manual Lock Valves And Manual
Emergency Lowering Facility. Emergency Lowering Facility.
1 Double Acting Lift (Jib) Cylinder 1 Double Acting Lift (Jib) Cylinder
Control System One handed Proportional Joystick One handed Proportional Joystick
Operating Energy Efficient Motor Operating Energy Efficient Motor
Control System. Control System.
Tyres 185 R13 6PLY 185 R13 6PLY
Brake System Automatic Reverse & Overrun Brakes Automatic Reverse & Overrun Brakes
Handbrake Handbrake
Maximum Continuous Sound
Pressure Level At Operation
Stations
74.6 dB(A) 74.6 dB(A
* Outriggers Deployed at full height = Minimum footprint
** Outriggers Deployed at min. height = Maximum footprint
*** Subject to local regulations
