Snorkel S2633 User Manual
Page 8
Page 4
2 G
ENERAL
D
ESCRIPTION
2 G
ENERAL
D
ESCRIPTION
D A N G E R
!
!
DO NOT use the machine if all guardrails are not properly in place and secured.
Figure 2: S2633
1. Platform Controls
2. Operator Manual Case
3. Platform Extension
4. Platform
5. Elevating Assembly
6. Chassis
7. Batteries
8. Charger Outlet Plug
9. Chassis Controls
10. Emergency Lowering Valve Knob
11. Hydraulic Fluid Reservoir
