11 S PECIFICATIONS
Page 21
11 S PECIFICATIONS
Specifications are subject to change without notice. Hot environment or heavy use may affect
performance. Refer to the Service Manual for complete parts and service information.
Meets or exceeds all applicable CE and GS machinery directive requirements.
ITEM S2633
Platform Size
Platform Extension In 0,71 m x 2,21 m [28 in. x 87 in.]
Platform Extension Out 0,71 m x 3,20 m [28 in. x 126 in.]
Max. Platform Capacity
Standard 340 kg [750 lbs.]
on Extension 110 kg [250 lbs.]
Max. No. of occupants
Standard (total) 3 people
on Extension 1 person
Maximum Wheel Load 818 kg [1,800 lbs.]
Maximum Chassis Inclination 1,5° side/side - 2,5° front/rear
Height
Working Height 9,93 m [32.5 ft.]
Max. Platform Height 7,93 m [26 ft.]
Min. Platform Height 1,09 m [43 in.]
Dimensions
Weight 2358 kg [5200 lbs.]
Overall Width 0,82 m [32.5 in.]
Overall Height 2,19 m [86 in.]
Overall Height, Rails Lowered 1,99 m [78.25 in.]
Overall Length, Extension In 2,35 m [92.5 in.]
Overall Length, Extension Out 3,26 m [128.5 in.]
Drivable Height 7,93 m [26 ft.]
Drive Speed
Platform Lowered 0 to 3,2 km/h [0 to 2.0 mph]
Platform Raised 0 to 0,8 km/h [0 to 0.50 mph]
Energy Source 24 Volt Battery Pack (4-235 A Hour, 6 Volt Batteries, min. wt. 30 kg [66 lbs.] each)
Motor 24 Volt 4 Horse Power DC Electric Motor
System Voltage 24 Volt DC
Battery Charger 25 A, 110/220 VAC
Hydraulic Reservoir Capacity 15 L [4 US Gallons]
Maximum Hydraulic Pressure 207 bar [3000 psi]
Hydraulic Fluid
Normal Temperature (0° C [>32° F]) ISO #32
Low Temperature (0° C [<32° F]) ISO #32
Extreme Temperature (-17° C [<0° F]) ISO #15
Lift System One Single Stage Lift Cylinder
Lift Speed Lift, 42 sec./Lower 40 sec.
Control System
Proportional Control Handle with Interlock Switch, Rotary Lift/Drive Switch, and Red
Mushroom Emergency Stop Switch
Drive System Dual Front Wheel Hydraulic Motors
Tyres 381 mm [15 in.] Diameter Solid Rubber, non-marking
Parking Brake Dual Spring Applied, Hydraulic Release
Turning Radius 203 mm [8 in.] Inside
Maximum Gradeability 14,5° [26%]
Wheel Base 1,9 m [74.75 in.]
Guardrails 1,1 m [43.25 in.] High
Toe Boards 152 mm [6 in.]
Ground Clearance 89 mm [3.5 in.]
