7 O PERATION
Page 11
F OLD D OWN G UARDRAILS
The guardrails may be lowered for the purpose of passing through a standard doorway.
Guardrails must be returned to proper position before using the machine.
W A R N I N G ! !
DO NOT use the machine if all guardrails are not properly in place and secured.
This procedure applies only for the purpose of passing through a standard double doorway.
L OWERING P ROCEDURE
1. Unhook the controller from the side guardrail and place it on the floor of the platform.
2. Pull the retaining pin on the front guardrail and rotate inwards.
3. Pull the retaining pin on the rear guardrail and rotate inwards.
4. Starting with the slide-out deck guardrails and then the outer guardrails, lift up on each guardrail and fold
inward.
E RECTION P ROCEDURE
1. Starting with the outer guardrails and then the slide-out deck guardrails, raise each guardrail and drop it
down, securing it in the vertical position.
2. Rotate the front and rear upper guardrails outward and secure them to the opposite side guardrails,
using the retaining pins.
3. Hang the controller on the side guardrail.
C A U T I O N ! !
Guardrails must be returned to proper position before using the machine.
