Chassis – push 6 pro/push 8 pro/push 10 pro – Snorkel PUSH 10 PRO-sn01-000050+CE User Manual
Page 7
PUSH 6 PRO / PUSH 8 PRO / PUSH 10 PRO – 0120877
Repair Parts – 7
1
512897-000
1
BASE WELDMENT
2
0120675
1
ARM WELDMENT
3
0120676
1
ARM WELDMENT
4
0120671
1
PIN
5
0120667
2
LINK
6
0120668
1
LINK
7
5554375
5
COLLAR SHAFT 15MM
8
0120670
1
BAR HEX
9
0120664
2
WHEEL ASSY FIXED CASTOR
10
5560364
4
M10 FLAT WASHER DIN 125
11
5560719
21
NUT HEX LKG M10-1.50
12
5560613
2
WSHR FLAT M8
13
5560355
2
WSHR LOCK M8
14
0120663
2
WHEEL ASSY SWIVEL CASTOR
15
513242-000
2
BUMPER W/M10 X 1.5 THREADED STUD
16
2509723
4
BRG 25MM ID X 28MM OD X 30MM LG
17
0120682
1
WELDMENT PIN
18
5560356
1
WSHR LOCK M10 DIN 127
19
0120751
1
COVER PLATE
20
0120680
2
SLIDE
21
058503-025
6
SHCS M8 X 1.25 X 25 G8.8 ISO 4762 BLACK OXIDE
22
5560727
6
NUT HEX LKG M8-1.25
23
512240-801
1
TRAY SUB ASSY PUSH (STAGE 1)
24
5534378
2
SPRING
25
5563250
2
ROLL PIN 6M X 30
26
0120560
1
KEEPER PIN
27
5560629
4
M6 FLAT WASHER DIN 125
28
5560664
4
WSHR LOCK M6 DIN 127
29
5563128
1
BLT FLSKTHD M8-1.25 25
30
5563263
16
SBHCS M10 X 1.50 X 25 GR 10.9 BLK FINISH
31
5563267
1
SBHCS M10 X 1.50 X 45 GR 10.9 BLK FINISH
32
5563279
4
SBHCS M6 X 1.0 X 12 GR 10.9 BLK FINISH
33
5563297
2
SBHCS M8 X 1.25 X 16 GR 10.9 BLK FINISH
34
5563260
1
SBHCS M10 X 1.50 X 16 GR 10.9 BLK FINISH
35 107080-000
1
D-RING BRACKET
36 107080-001 1
D-RING
37
5560357
2
HHCS M8 X 1.25 X 25 G8.8 ISO 4017_DIN 933
38
512329-000
1
HYDRAULIC HOSE SECURING BUSH
39
058501-016
2
M5 X 16 S.H.C.S.- GR 12.9
40 0120844
1
TILT SWITCH ASSY
41 058500-010
6
M4 X 10 SOCKET HD CAP SCREW - 12.9
42 0120806
1
STACK LIMIT SWITCH
43 0120807
1
MOUNTING BRK. - LIMIT SWITCH
44 0120808
1
COVER - LIMIT SWITCH
45
46 3220141
1
GRIP TAPE - STEP
47 510152-00
3
CABLE GLAND
Chassis – PUSH 6 PRO/PUSH 8 PRO/PUSH 10 PRO
Item
Part No.
Qty. Description
Chassis – PUSH 6 PRO/PUSH 8 PRO/PUSH 10 PRO
