Upper control box wiring harness – Snorkel PUSH 10 PRO-sn01-000050+CE User Manual
Page 26
Repair Parts – 26
PUSH 6 PRO / PUSH 8 PRO / PUSH 10 PRO – 0120877
1
3220153
1
PLUG 6 PIN DEUTSCH
2
3049895
6
SOCKET CONTACT -20 DEUTSCH
3
63 IN
CABLE 6 COND 20 GA
4
3040047
2
TERMINAL FEM250 22/18
5
3049860
1
LOCK WEDGE 6 PIN
Upper Control Box Wiring Harness
Item
Part No.
Qty. Description
0120842
Upper Control Box Wiring Harness
To Scissor Stack
Wiring Harness
To Upper
Control Box
