Snorkel PUSH 10 PRO-sn01-000050+CE - Manual (Page 11)

PUSH 6 PRO / PUSH 8 PRO / PUSH 10 PRO – 0120877 Repair Parts – 11
1 0120830 1 WLDMT, TRAY
2 0120827 1 CHARGER SIGNET 12V
3 3050002 1 BATTERY 12V
4 510524-000 1 PUSH/PULL SW ASSY W/NC CONTACT
5 509472-000 1 SW TGL SPDT (ON) OFF (ON)
6 0120801 1 CHARGER PLUG YELLOW 110/130VBLUE
7 0120802 1 CHARGER PLUG BLUE 200/250V
8 5569887 8 M4 FLAT WASHER DIN 125
9 5563245 8 WSHR LOCK M4 DIN 127
10 5563131 12 BLT HEXHD M4-0.7 16MM
11 003570-005 1 RETAINING PIN ASSY
12 502588-000 1 ALARM, SOUNDER
13 3040508 1 TIME DELAY MODULE
14 512314-000 4 RELAY SPDT 12V 40AMP
15 0120803 1 RAISE PUSH BUTTON
16 0120804 1 LOWER PUSH BUTTON
17 5563011 6 NUT LKG M4-0.70
18 0120878 1 TRAY BRACKET, PUSH
19 510542-000 1 ENABLE PUSH BUTTON
20 512253-000 1 TERMINAL STRIP (12)
21 5563249 2 SHCS M4 X 0.7 X 25 G8.8 ISO 4762 ZINC PLATED - BRIGHT CROMATED
22 0120834 2 BLOCK, TRAY STOP
23 5560664 8 WSHR LOCK M6 DIN 127
24 5560690 4 HHCS M6 X 1 X 18 G8.8 ISO 4017 DIN 933
25 510526-000 1 KEY SWITCH
26 5563248 4 SHCS M6 X 1 X 12 G12.9 ISO 4762 ZINC PLATED - BRIGHT CROMATED
27 513408-000 1 POWER UNIT
28 5560364 2 M10 FLAT WASHER DIN 125
29 5560356 2 WSHR LOCK M10 DIN 127
30 972019 2 BLT HEXHD M10-1.5 X 25MM
31 513806-000 2 DIODE ASSEMBLY
32 510527-000 2 CONTACT BLOCK N/O
33 512907-000 1 CHARGER LEAD
34 514018-000 1 ELBOW ADAPTOR - 3/8" BSP X 4 ORFS
35 3040469 1 START RELAY - 12V (SHOWN ON 514042-000)
36 446086 1 FUSE HOLDER
37 446076 1 FUSE - 250 AMP
38 513166-000 1 CABLE ASSEMBLY
39 513169-000 1 CABLE ASSEMBLY
40 513165-000 1 CABLE ASSEMBLY
3040268 4 BOOT BATTERY CABLE END BLOCK
Tray (Current)
Tray
Item Part No. Qty. Description
SERIAL NO BREAK:
PUSH 6 - 000129+
PUSH 8 - 000541+
PUSH 10 - 000099+
