PUSH 6 PRO / PUSH 8 PRO / PUSH 10 PRO – 0120877
Repair Parts – 25
1
2
513244-000
1
CONN 14 PIN DEUTSCH PLUG
3
509540-000
16
SOCKET CONTACT -16 DEUTSCH
4
3049890
2
LOCK WEDGE 4 PIN
5
3049888
2
PLUG 4 PIN DEUTSCH
6
3040047
2
TERMINAL FEM250 22/18
7
509539-000
6
PIN -16 DCH
8
3220152
1
RECEPTACLE DEUTSCH
9
200 IN
CABLE 3 COND 18 GA
10
3011820
85 IN
CABLE 2 COND 18 GA
11
40 IN
CABLE 5 COND 18 GA
12
3049886
1
LOCK WEDGE 6 PIN
13
14
0120844
1
TWO AXIS TILT SWITCH ASSEMBLY (TILT SETTINGS X - 2 °, Y - 2 °)
15
510143-000
2
M4 RING TERMINAL
Scissor Stack Wiring Harness
Item
Part No.
Qty. Description
A B C D E F G H J K L M N P
11
36
16
22
40
17
32
3
37
14
33
30
36
37
32
3
33
17
1 2 3 4
6 5 4 3 2 1
14
3
16
22
11
2
3
3
4
5
7
8
11
10
15
3
9
NOTE! VIEW SHOWING REAR INSERT DEUTSCH PLUG : SHELL SIZE 18 - (14 x SIZE 16 SOCKETS)
P
N
M
L
K
J
H
G
F
E
D
C
B
A
12
40
30
3A
3A
6
1 2 3 4
R
YL
BL
BK
14
0120838
Scissor Stack Wiring Harness
To upper controls
To Level
Sensor
To Stack
Switch
To Tray
Wiring Harness
To cylinder
Harness
