2 - 8
2. Operation & Specifications
L
OWER
C
ONTROL
P
ANEL
4 Steering Switch Turns the wheels left or right.
5 Selector Switch
6
7
8
9
10
Use to warn bystanders or to attract attention.
I TEMS N AMES F UNCTION
I
TEMS
N
AMES
F
UNCTION
1
2 Key Switch Selects Platform controls, OFF, or lower controls.
3
4
5
6
Emergency Stop
Push this red button at any time to isolate power.
Turn clockwise to reset.
Pre selects Jib, Mast or Mast Rotate function.
Drive / Lift Selector Pre selects either drive or lift function.
Low / High Torque Selector
In drive function pre-selects low torque high speed drive
or high torque low speed drive, only functions when mast
and jib are down.
Horn Button
Illuminates when battery charge is low and machine
automatically switches into limp mode.
Low battery warning lamp
Overload warning lamp Illuminates when load in basket exceeds SWL
Rocker Switch Activates the Pre-Selected operation, in either direction.
Selector Switch Pre-selects Jib, Mast or Mast Rotate function.
Enable Switch
This Switch Enables the rocker switch and must be
held up during operation.
Hour Meter / BCI
Displays total run time of the machine and an indication
of remaining battery capacity.
Table 2: Lower controls and Indicators
