Operation

067903-004R1 LX Series Work Platform

Operator Manual

Page 7

O

PERATION

NOTE: Before operating the work platform, ensure that the pre-operation and safety inspection has been completed,

any deficiencies have been corrected, and the operator has been thoroughly trained on this machine.

W A R N I N G

!

!

Never operate the work platform with the parking brakes released. Serious injury or damage could
result.

S

W I T C H I N G

F

U E L S

( D

U A L

F

U E L

O

N L Y

)

1. With the engine running, turn the fuel selector switch (Figure 3: “Controls and Indicators,” on page 4) to

the center position.

2. After the engine has quit running, select the appropriate fuel supply.

3. Restart the engine.

T

R A V E L

W I T H

P

L A T F O R M

L

O W E R E D

1. Verify the following:

• the chassis Emergency Stop button is in the ON position (pull out)
• the drive enable indicator is ON
• the Platform/Chassis switch is on PLATFORM.

NOTE: If the drive enable indicator is OFF, verify that the platform is fully lowered and (if so equipped) the outriggers

are fully retracted.

2. After mounting the platform, close and latch the gate. Check that the guardrails are in position and prop-

erly assembled, with the fasteners properly torqued.

3. Check that the route is clear of persons, obstructions, holes and drop-offs, and is capable of supporting

the wheel loads.

4. Check clearances above, below and to the sides of the platform.

5. Pull the controller Emergency Stop button out to the ON position.

6. Turn the controller key switch fully clockwise to start the engine, releasing the key once the engine

starts.

NOTE: If the engine is cold, on dual fuel models, depress and hold the choke button in while starting the engine. On

diesel models, hold the glow plug button in for 6 seconds to heat the glow plugs.

7. Set the Lift/Drive switch to DRIVE.

8. Set the speed range switch to HIGH TORQUE.

9. Grasp the control lever so that the interlock lever switch is depressed (releasing the interlock lever switch

cuts power to controller). Slowly push or pull the control lever to FORWARD or REVERSE to travel in the
desired direction. The farther you push or pull the control lever from center, the faster the machine will
travel.

10. While moving, push the speed range switch to HIGH SPEED for travel on level surfaces or to HIGH

TORQUE for climbing grades or traveling in confined areas.
