Operator Manual

067903-004R1 LX Series Work Platform

Specifications

S

PECIFICATIONS

Specifications subject to change without notice. Refer to the Service Manual for service information. Refer
to the Parts Manual for illustrated parts breakdown. Hot weather or heavy use may reduce performance.
Meets or exceeds all applicable requirements of OSHA and ANSI A92.6-1999.

ITEM

LX31

LX41

LX50

Platform Size (Inside toeboards)

Standard

3,97 m x 1,73 m [156 in x 68 in.]

3,97 m x 1,73 m [156 in x 68 in.]

3,97 m x 1,73 m [156 in x 68 in.]

slide-out Deck Extended

4,8 m x 1,73 [190 in. x 68 in.]

4,8 m x 1,73 [190 in. x 68 in.]

4,8 m x 1,73 [190 in. x 68 in.]

Max. Platform Capacity

Standard

907 kg [2,000 lbs.]

680 kg [1,500 lbs.]

454 kg [1,000 lbs.]

Dual Deck

794 kg [1750 lbs.]

567 kg [1,250 lbs.]

340 kg [750 lbs.]

on Extension

227 kg [500 lbs.]

227 kg [500 lbs.]

227 kg [500 lbs.]

Max. No. of occupants

Standard

5 people

5 people

4 people

Dual Deck

4 people

3 people

Height

Working Height

11,4 m [37 ft.]

14,33 m [47 ft.]

17 m [56 ft.]

Max. Platform Height

9,45 m [31 ft.]

12,34 m [40 ft. 6 in.]

15,09 m [49 ft. 6 in.]

Min. Platform Height

1,43 m [56.3 in.]

1,66 m [65.3 in.]

1,93 m [76 in.]

Drivable Height, Standard

9,4 m [31 ft.]

12,3 m [40 ft. 6 in.]

12,34 m [49 ft. 6 in.]

Drivable Height, Dual Deck

12,2 m [40 ft.]

Dimensions

Weight, Standard

2WD:
4WD:

4282 kg [9,440 lbs.]
4404 kg [9,710 lbs.]

4994 kg [11,010 lbs.]

5117kg [11,280 lbs.]

GAS: 5756 kg [12,690 lbs.] DIES: 5788 kg [12,760 lbs.]
GAS: 5879 kg [12,960 lbs.] DIES: 5910 kg [13,030 lbs.]

Weight, Dual Deck

2WD:
4WD:

4613 kg [10,170 lbs.]
4736 kg [10,440 lbs.]

5325 kg [11,740 lbs.]
5448 kg [12,010 lbs.]

GAS: 6087 kg [13,420 lbs.] DIES: 6119 kg [13,490 lbs.]

GAS: 6210 kg [13,690 lbs.] DIES:6241 kg [13,760 lbs.]

Overall Width

2,29 m [90 in.]

2,29 m [90 in.]

2,29 m [90 in.]

Overall Height, guardrails up

2,53 m [99.8 in.]

2,77 m [109 in.]

3 m [118.3 in.]

Overall Height, guardrails lowered

1,64 m [64.5 in.]

1,87 m [73.5 in.]

2,1 m [82.5 in.]

Overall Length, deck in

4,06 m [160 in.]

4,06 m [160 in.]

4,06 m [160 in.]

Overall Length, deck extended

4,88 m [192 in.]

4,88 m [192 in.]

4,88 m [192 in.]

Surface Speed

Platform Lowered

0 to 5,0 km/h [0 to 3.1 mph]

0 to 5,0 km/h [0 to 3.1 mph]

0 to 5,0 km/h [0 to 3.1 mph]

Platform Raised

0 to 0,48 km/h [0 to 0.5 mph]

0 to 0,48 km/h [0 to 0.5 mph]

0 to 0,48 km/h [0 to 0.5 mph]

System Voltage

12 Volt DC

12 Volt DC

12 Volt DC

Hydraulic Tank Capacity

107,13 l [28.3 US Gallons]

107,13 l [28.3 US Gallons]

107,13 l [28.3 US Gallons]

Maximum Hydraulic System Pressure

206,8 bar [3000 psi]

206,8 bar [3000 psi]

206,8 bar [3000 psi]

Hydraulic Fluid

Normal Temperature (>32° F [0° C])

ISO #46

ISO #46

ISO #46

Low Temperature (<32° F [0° C])

ISO #32

ISO #32

ISO #32

Extreme Temperature (<0° F [-17° C])

ISO #15

ISO #15

ISO #15

Lift System

One Single Stage Lift Cylinder

One Single Stage Lift Cylinder

Two Single Stage Lift Cylinders

Lift Speed

Raise: 40 sec. Lower: 52 sec.

Raise: 45 sec. Lower: 60 sec.

Raise: 80 sec. Lower: 112 sec.

Power Source

Diesel or Gasoline 20 HP Kubota,

3 Cylinder, Water Cooled

Diesel or Gasoline 20 HP Kubota,

3 Cylinder, Water Cooled

Diesel or Gasoline 20 HP Kubota, 3 Cylinder, Water Cooled

Drive Control

Proportional

Proportional

Proportional

Control System

Smooth one-hand Joystick

Smooth one-hand Joystick

Smooth one-hand Joystick

Horizontal Drive

2WD:
4WD:

2 Wheel, Hyd. Motors
4 Wheel, Hyd. Motors

2 Wheel, Hyd. Motors
4 Wheel, Hyd. Motors

2 Wheel, Hyd. Motors
4 Wheel, Hyd. Motors

Tires

10-16.5 NHS 8 Ply

10-16.5 NHS 8 Ply

10-16.5 NHS 8 Ply

Tire Air Pressure

3,4 bar [50psi.]

3,4 bar [50psi.]

NA

Parking Brakes

Dual Disc, Spring Applied,

Hydraulic Release

Dual Disc, Spring Applied,

Hydraulic Release

Dual Disc, Spring Applied, Hydraulic Release

Turning Radius (inside)

1,22 m [48 in.]

1,22 m [48 in.]

1,22 m [48 in.]

Maximum Gradeability:

2WD:
4WD:

17° [30%]
19° [35%]

17° [30%]
19° [35%]

13,5° [24%]
13,5° [24%]

Wheel Base

2WD:
4WD:

2,9 m [114.5 in.]

2,95 m [116 in.]

2,9 m [114.5 in.]

2,95 m [116 in.]

2,9 m [114.5 in.]

2,95 m [116 in.]

Ground Clearance

0,24 m [9.5 in.]

0,24 m [9.5 in.]

0,24 m [9.5 in.]

Guardrails

1.1 m [43.5 in.] high,

Fold Down with gate.

1.1 m [43.5 in.] high,

Fold Down with gate.

1.1 m [43.5 in.] high,

Fold Down with gate.

Toeboard

152 mm [6 in.] High

152 mm [6 in.] High

152 mm [6 in.] High
