than this combination of parts skip to step 5 to determine the correct shock
relocation bracket position.
4. Use these measurements in conjunction with the collapsed shock length
measurement to determine the mounting location of the 8074 shock brackets.
APPROXIMATE COLLAPSED SHOCK LENGTHS
LCA LENGTH = 20-1/4"
UCA LENGTH = 18-1/8"
BOLT HOLES 2" TALL BUMP-
STOP SPACER
3” TALL BUMP-
STOP SPACER 4” TALL BUMP-STOP
SPACER
TOP 15-5/8" 16-7/16" 17-5/16"
MIDDLE 16-1/4" 17-1/8" 18"
LOWEST 16-7/8" 17-3/4" 18-11/16"
APPROXIMATE COLLAPSED SHOCK LENGTHS
STOCK UPPER & LOWER CONTROL ARMS
BOLT HOLES NO BUMP-
STOP
SPACER 2" TALL
BUMP-STOP
SPACER 3” TALL
BUMP-STOP
SPACER 4” TALL
BUMP-STOP
SPACER
TOP 13-13/16" 15" 15-15/16" 16-3/4"
MIDDLE 14" 15-9/16" 16-3/8" 17-1/4"
LOWEST 14-5/8" 16-1/4" 17" 17-15/16"
5. Put the rear of the chassis on jack stands. Remove the rear tires and wheels and
springs.
6. Remove the jounce bumpers but leave any bump stop extension brackets you may
have. Jack the rear axle up to compress the suspension until the axle bumpstop
pad or bumpstop spacer hits the metal cup that holds the jounce bumpers. This
should be the highest the rear axle and suspension will travel.
7. Using the factory shock bolts, attach the shock relocation brackets to the bottom
bushing of the shock.
8. Compress the shock and position the bracket on the back of the lower control arm
bracket to determine which set of holes to use.
