Lukas Concrete crushers User Manual
Page 38
38
CAUTION!
Take care that the port ‘T’ of the rescue tool is always connected to the port ‘T’
of the mono-coupling.
2. Loosen the connection nuts of the hose assembly and remove the coupling.
10.3.4 Mono-couplings
The mono-couplings on the connection hoses on the equipment must be replaced if:
- there is external damage
- the locking mechanism does not work
- hydraulic fluid continues to leak in the coupled/uncoupled state.
3.
Position the new coupling and tighten the union nuts on the hose lines to a
torque of M
A
= 40 Nm and push the cover back over the couplings.
WARNING / CAUTION!
Never repair couplings: they must be replaced by original LUKAS parts!
During assembly, tighten the union nuts on the hose line to a torque of M
A
= 40 Nm.
Procedure:
1. Remove the cover from the couplings.
