Lukas SC 350 E - Manual (Page 38)

38
11. Technical data
11.1 eDRAULIC cutter
Type S 311 E S 700 E
Ref.no. 90-20-20 (172090000) 90-20-70 (172080000)
Dimensions (without battery)
l x w x h
[mm] 860 x 225 x 290 925 x 300 x 290
[in.] 33.86 x 8.86 x 11.42 36.42 x 11.81 x 11.42
Max. cutting opening
[mm] 150 185
[in.] 5.91 7.28
Weight (excl. battery)
[kg] 19,4 24,5
[lbs.] 42.8 54.0
Nominal electrical voltage
(with power supply)
[V] 24
Nominal electrical voltage
(with lithium/ion battery)
[V] 25,2
Protection category IP44
Classifi cation (NFPA 1936) A7/B8/C6/D7/E7 A8/B9/C8/D9/E9
NOTE:
The following tables contain only the technical data necessary for operation and
storage.
Further information about your device is available directly from LUKAS.
Since all values are subject to tolerances, minor differences may occur between the data on
your equipment and the data in the following tables.
The values may also differ because of reading inaccuracies and/or tolerances in the
measuring equipment used.
