Pinout
23
© 2014 AEM Performance Electronics
C1-49
+5V_Out
+5V Sensor
Power
72, 73
Regulated, f used +5V supply f or
sensor power
Analog sensor power.
C1-50
+5V_Out
+5V Sensor
Power
83, 98
Regulated, f used +5V supply f or
sensor power
Analog sensor power.
C1-51
Analog_In_7
DBW TPS1
84
12 bit A/D, 100K pullup to 5V
PnP f or TPS1 input f rom DBW throttle body .
C1-52
Analog_In_8
Boost/MAP
Sensor
101
12 bit A/D, 100K pullup to 5V
MAP input. Use included Boost/MAP sensor adapter
harness.
C1-53
Analog_In_9
Fuel Pressure
Aux 1
12 bit A/D, 100K pullup to 5V
Can be used as a Fuel Pressure input f or f uel deliv ery
calculation. See the Setup Wizard Fuel Pressure page
f or setup and calibration. Monitor the FuelPressure
[psig] channel.
C1-54
VR+_In_2
Not used
No connect
Dif f erential Variable Reluctance
Zero Cross Detection
Not used.
C1-55
VR-_In_2
Not used
No connect
C1-56
VR-_In_3
Not used
No connect
Dif f erential Variable Reluctance
Zero Cross Detection
Not used.
C1-57
VR+_In_3
Not used
No connect
C1-58
HighsideSwitch_0
Not used
No connect
2.6A max, High Side Solid State
Relay
Not used.
C1-59
Stepper_1B
Not used
No connect
Automotiv e, Programmable Stepper
Driv er, up to 28V and ±1.4A
Not used.
C1-60
Stepper_2B
Not used
No connect
Automotiv e, Programmable Stepper
Driv er, up to 28V and ±1.4A
Not used.
C1-61
DBW1 Motor-
DBW Throttle
Close
118
5.0A max Throttle Control Hbridge
Driv e
PnP DBW throttle control. Base session is conf igured
f or stock DBW TB. Other TB's may be used but will
require setup and characterization. See Driv e By Wire
Wizard.
C1-62
DBW1 Motor+
DBW Throttle
Open
117
5.0A max Throttle Control Hbridge
Driv e
PnP DBW throttle control. Base session is conf igured
f or stock DBW TB. Other TB's may be used but will
require setup and characterization. See Driv e By Wire
Wizard.
C1-63
+12v
+12v
121
12v power f rom main relay
12v power f rom main relay .
C1-64
Injector 6
Not used
No connect
Peak and hold, 3A max f or Inf inity -
6. Saturated injector driv er f or
Inf inity -8h.
Not used.
C1-65
Injector 5
Not used
No connect
Peak and hold, 3A max f or Inf inity -
6. Saturated injector driv er f or
Inf inity -8h.
Not used.
C1-66
Injector 4
Injector 4
88
Peak and hold, 3A max f or Inf inity -
6. Saturated injector driv er f or
Inf inity -8h.
Injector 4.
C1-67
Power Ground
Ground
2
Power ground
Power ground.
C1-68
+12v
Not used
No connect
12v power f rom main relay
Not used.
C1-69
Analog_In_19
DBW APP2
34
12 bit A/D, 100K pullup to 5V
PnP f or Accelerator Pedal Position Sensor 2.
C1-70
Analog_In_18
DBW APP1
35
12 bit A/D, 100K pullup to 5V
PnP f or Accelerator Pedal Position Sensor 1.
C1-71
Analog_In_16
DBW TPS2
92
12 bit A/D, 100K pullup to 5V
PnP f or TPS2 input f rom DBW throttle body .
C1-72
Flash Enable
Flash Enable
Flash Enable
Connector
10k pulldown
Two pin DTM connector in AEM adapter harness. Use
only to f orce EMS into f lash mode if normal f irmware
update procedure does not work.
C1-73
Analog_In_13
Spare Analog
Input
Aux 4
12 bit A/D, 100K pullup to 5V
Can be used as Oil Pressure, Mode Switch, 3-Step or
other analog input. See Oil Pressure or Input Function
Assignments in Setup Wizard.
C1-74
Analog_In_11
Spare Analog
Input
Aux 3
12 bit A/D, 100K pullup to 5V
Can be used as Shif tSwitch, Mode Switch, 3-Step or
other analog input. See Shif t Cut or Input Function
Assignments in Setup Wizard.
C1-75
Analog_In_10
Spare Analog
Input
Aux 2
12 bit A/D, 100K pullup to 5V
Can be used as Barometric Pressure, Mode Switch, 3-
Step or other analog input. See Barometric Pressure or
Input Function Assignments in Setup Wizard.
