25-131
Instructions 10-131 Page 4 of 4 8.24.2007 Rev A
For technical inquiries
e-mail us at [email protected]
or
call us at
310.484.2322 Option #3
4. Installation of the AEM Fuel Rail.
a) Install the AEM fuel rail by placing the injectors into the injector seals in the intake manifold with the AEM logo on the fuel rail facing upward.
b) Secure the fuel rail to the intake manifold using the factory 8mm bolts.
c) Lubricate the fuel pressure regulator o ring, and the passengers side fuel rail bore, and carefully install the regulator into the fuel rail.
d) Secure the regulator using the original 6mm bolts.
e) Lubricate the fuel supply line o ring, and the drivers side fuel rail bore, and carefully insert the fuel supply line into the driver side of the fuel
rail.
f) Secure the fuel supply line using the factory 6mm bolts.
5. Final Checks
a) Before starting the engine, activate the ignition key to the run position 2 or 3 times to prime the fuel system. Check for leaks at the injectors,
and ends of the fuel rail.
b) Providing there are NO leaks start the engine and re-check for leaks.
c) Correct any leaks before driving the vehicle.
